270C LC Lift Capacities
Boldface italic type indicates hydraulic-limited capacities; lightface type indicates stability-limited capacities, in lb. (kg). Ratings at bucket lift hook; machine equipped with 1.75-cu. yd. (1.34 m 3 ),
42-in. (1065 mm) wide, 1,966-lb. (892 kg) bucket; and situated on firm, uniform supporting surface. Total load includes weight of cables, hook, etc. Figures do not exceed 87 percent of hydraulic
capacities or 75 percent of weight needed to tip machine. All lift capacities are with power boost and are based on SAE J1097.
Load Point 10 ft. (3.05 m) 15 ft. (4.57 m) 20 ft. (6.10 m) 25 ft. (7.62 m) 30 ft. (9.15 m)
Height Over Front Over Side Over Front Over Side Over Front Over Side Over Front Over Side Over Front Over Side
With 10-ft. 2-in. (3.10 m) arm and 24-in. (600 mm) shoes
20 ft. (6.10 m) 9,998 (4535) 9,988 (4530)
15 ft. (4.57 m) 10,841 (4917) 10,238 (4644) 7,014 (3181) 7,014 (3181)
10 ft. (3.05 m) 19,987 (9066) 19,987 (9066) 14,695 (6666) 14,190 (6436) 12,438 (5642) 9,771 (4432) 10,732 (4868) 6,989 (3170)
5 ft. (1.52 m) 26,941 (12 220) 20,321 (9217) 18,092 (8206) 13,221 (5997) 14,278 (6476) 9,268 (4204) 11,565 (5246) 6,744 (2964)
Ground Line 24,266 (11 007) 19,439 (8817) 20,643 (9364) 12,543 (5689) 15,236 (6911) 8,862 (4020) 11,336 (5142) 6,534 (2786)
–5 ft. (–1.52 m) 11,720 (5316) 11,720 (5316) 30,593 (13 877) 19,266 (8739) 21,509 (9756) 12,226 (5546) 14,980 (6795) 8,632 (3915) 10,811 (4904) 6,439 (2921)
–10 ft. (–3.05 m) 22,082 (10 016) 22,082 (10 016) 29,398 (13 335) 19,416 (8807) 21,487 (9746) 12,207 (5537) 14,963 (6787) 8,617 (3909)
–15 ft. (–4.57 m) 34,463 (15 632) 34,463 (15 632) 26,341 (11 948) 19,850 (9004) 19,736 (8952) 12,476 (5659)
–20 ft. (–6.10 m) 19,690 (8931) 19,690 (8931)
With 12-ft. 4-in. (3.75 m) arm and 24-in. (600 mm) shoes
15 ft. (4.57 m) 9,499 (4309) 9,499 (4309) 8,346 (3786) 7,317 (3319)
10 ft. (3.05 m) 12,902 (5852) 12,902 (5852) 11,214 (5087) 9,931 (4505) 10,397 (4716) 7,072 (3208)
5 ft. (1.52 m) 23,934 (10 856) 21,010 (9530) 16,527 (7497) 13,480 (6114) 13,221 (5997) 9,371 (4251) 11,506 (5219) 6,774 (3073)
Ground Line 28,654 (12 997) 19,638 (8908) 19,537 (8862) 12,652 (5739) 15,055 (6829) 8,887 (4031) 11,317 (5133) 6,504 (2950)
–5 ft. (–1.52 m) 13,075 (5931) 13,075 (5931) 30,367 (13 774) 19,155 (8689) 21,337 (9678) 12,185 (5527) 14,928 (6771) 8,571 (3888) 11,127 (5047) 6,329 (2871)
–10 ft. (–3.05 m) 23,260 (10 551) 23,260 (10 551) 30,084 (13 646) 19,140 (8682) 21,320 (9671) 12,043 (5463) 14,802 (6714) 8,457 (3836) 9,313 (4224) 6,321 (2867)
–15 ft. (–4.57 m) 35,784 (16 231) 35,784 (16 231) 27,986 (12 694) 19,445 (8820) 20,706 (9392) 12,184 (5527) 14,951 (6782) 8,591 (3897)
–20 ft. (–6.10 m) 32,182 (14 598) 32,182 (14 598) 23,188 (10 518) 20,123 (9128) 16,916 (7673) 12,693 (5757)
With 10-ft. 2-in. (3.10 m) arm and 32-in. (800 mm) shoes
20 ft. (6.10 m) 9,998 (4535) 9,988 (4530)
15 ft. (4.57 m) 10,841 (4917) 10,602 (4809) 7,014 (3181) 7,014 (3181)
10 ft. (3.05 m) 19,987 (9066) 19,987 (9066) 14,695 (6666) 14,671 (6655) 12,438 (5642) 10,135 (4597) 10,732 (4868) 7,282 (3303)
5 ft. (1.52 m) 26,941 (12 220) 21,033 (9540) 18,092 (8206) 13,703 (6216) 14,278 (6476) 9,631 (4369) 12,029 (5456) 7,036 (3191)
Ground Line 24,266 (11 007) 20,151 (9140) 20,643 (9364) 13,025 (5908) 15,286 (6934) 9,225 (4184) 11,800 (5352) 6,826 (3096)
–5 ft. (–1.52 m) 11,720 (5316) 11,720 (5316) 30,593 (13 877) 19,979 (9062) 21,872 (9921) 12,707 (5764) 15,571 (7063) 8,996 (4080) 10,811 (4904) 6,732 (3054)
–10 ft. (–3.05 m) 22,082 (10 016) 22,082 (10 016) 29,398 (13 335) 20,219 (9130) 21,704 (9845) 12,689 (5756) 15,554 (7055) 8,980 (4073)
–15 ft. (–4.57 m) 34,463 (15 632) 34,463 (15 632) 26,341 (11 948) 20,563 (9327) 19,736 (8952) 12,957 (5877)
–20 ft. (–6.10 m) 19,690 (8931) 19,690 (8931)
With 12-ft. 4-in. (3.75 m) arm and 32-in. (800 mm) shoes
15 ft. (4.57 m) 9,499 (4309) 9,499 (4309) 8,346 (3786) 7,609 (3451)
10 ft. (3.05 m) 12,902 (5852) 12,902 (5852) 11,214 (5087) 10,295 (4670) 10,397 (4716) 7,365 (3341)
5 ft. (1.52 m) 23,934 (10 856) 21,723 (9853) 16,527 (7497) 13,962 (6333) 13,221 (5997) 9,734 (4415) 11,506 (5219) 7,066 (3205)
Ground Line 28,654 (12 997) 20,351 (9231) 19,537 (8862) 13,133 (5957) 15,055 (6829) 9,251 (4196) 11,781 (5344) 6,796 (3083)
–5 ft. (–1.52 m) 13,075 (5931) 13,075 (5931) 30,367 (13 774) 19,868 (9012) 21,337 (9678) 12,667 (5746) 15,519 (7039) 8,934 (4052) 11,591 (5258) 6,621 (3003)
–10 ft. (–3.05 m) 23,260 (10 551) 23,260 (10 551) 30,084 (13 646) 19,852 (9005) 21,795 (9886) 12,524 (5681) 15,393 (6982) 8,821 (4001) 9,313 (4224) 6,613 (3000)
–15 ft. (–4.57 m) 35,784 (16 231) 35,784 (16 231) 27,986 (12 694) 20,157 (9143) 20,706 (9392) 12,665 (5745) 15,542 (7050) 8,955 (4062)
–20 ft. (–6.10 m) 32,182 (14 598) 32,182 (14 598) 23,188 (10 518) 20,835 (9451) 16,916 (7673) 13,174 (5976)
200C LC Buckets
A full line of buckets is offered to meet a wide variety of applications. Digging forces are with power boost. The buckets have an adjustable bushing for side clearance, with the exception of the
ditching bucket. Tooth selection includes either the John Deere Fanggs
® , Standard, Tiger, Twin Tiger, Abrasion panel, or Flare tooth, or the ESCO (Vertalok) Standard, Tiger, Twin Tiger, or Flare tooth.
Replaceable cutting edges are available through John Deere parts. Optional side cutters add 6 inches (150 mm) to bucket widths.
Bucket Bucket Bucket Arm Dig Force Arm Dig Force Bucket
Type Bucket Width Capacity* Weight Dig Force 7 ft. 3 in. (2.22 m) 9 ft. 7 in. (2.91 m) Tip Radius No. Teeth
in. mm cu. yd. m 3 lb. kg lb. kN lb. kN lb. kN in. mm
General-Purpose 24 610 0.59 0.45 1,106 502 30,410 135.3 29,946 133.2 23,250 103.4 55.5 1410 4
Plate Lip 30 760 0.77 0.59 1,182 536 30,410 135.3 29,946 133.2 23,250 103.4 55.5 1410 4
36 915 0.95 0.73 1,401 635 30,410 135.3 29,946 133.2 23,250 103.4 55.5 1410 5
42 1065 1.12 0.86 1,590 721 30,410 135.3 29,946 133.2 23,250 103.4 55.5 1410 5
48 1220 1.30 0.99 1,673 759 30,410 135.3 29,946 133.2 23,250 103.4 55.5 1410 6
General-Purpose 30 760 0.95 0.73 1,391 631 29,348 130.5 29,531 131.4 22,979 102.2 57.5 1461 4
High Capacity 36 915 1.16 0.89 1,451 658 29,348 130.5 29,531 131.4 22,979 102.2 57.5 1461 5
42 1065 1.38 1.06 1,596 724 29,348 130.5 29,531 131.4 22,979 102.2 57.5 1461 5
48 1220 1.60 1.22 1,785 809 29,348 130.5 29,531 131.4 22,979 102.2 57.5 1461 6
*All capacities are SAE heaped ratings and with side cutters.
200C LC Buckets (cont.)
A full line of buckets is offered to meet a wide variety of applications. Digging forces are with power boost. The buckets have an adjustable bushing for side clearance, with the exception of the
ditching bucket. Tooth selection includes either the John Deere Fanggs
® , Standard, Tiger, Twin Tiger, Abrasion panel, or Flare tooth, or the ESCO (Vertalok) Standard, Tiger, Twin Tiger, or Flare tooth.
Replaceable cutting edges are available through John Deere parts. Optional side cutters add 6 inches (150 mm) to bucket widths.
Bucket Bucket Bucket Arm Dig Force Arm Dig Force Bucket
Type Bucket Width Capacity* Weight Dig Force 7 ft. 3 in. (2.22 m) 9 ft. 7 in. (2.91 m) Tip Radius No. Teeth
in. mm cu. yd. m 3 lb. kg lb. kN lb. kN lb. kN in. mm
Heavy-Duty 24 610 0.59 0.45 1,358 616 30,410 135.3 29,946 133.2 23,250 103.4 55.5 1410 4
Plate Lip 30 760 0.77 0.59 1,447 656 30,410 135.3 29,946 133.2 23,250 103.4 55.5 1410 4
36 915 0.95 0.73 1,567 711 30,410 135.3 29,946 133.2 23,250 103.4 55.5 1410 5
42 1065 1.12 0.86 1,676 760 30,410 135.3 29,946 133.2 23,250 103.4 55.5 1410 5
48 1220 1.30 0.99 1,759 798 30,410 135.3 29,946 133.2 23,250 103.4 55.5 1410 6
Heavy-Duty 24 610 0.73 0.56 1,401 635 29,348 130.5 29,531 131.4 22,979 102.2 57.5 1461 4
High Capacity 30 760 0.95 0.73 1,528 693 29,348 130.5 29,531 131.4 22,979 102.2 57.5 1461 4
36 915 1.16 0.89 1,629 739 29,348 130.5 29,531 131.4 22,979 102.2 57.5 1461 5
42 1065 1.38 1.06 1,701 771 29,348 130.5 29,531 131.4 22,979 102.2 57.5 1461 5
Severe-Duty 24 610 0.59 0.45 1,439 653 30,410 135.3 29,946 133.2 23,250 103.4 55.5 1410 3
Cast Lip 30 760 0.77 0.59 1,551 703 30,410 135.3 29,946 133.2 23,250 103.4 55.5 1410 4
36 915 0.95 0.73 1,629 739 30,410 135.3 29,946 133.2 23,250 103.4 55.5 1410 4
Severe-Duty 30 760 0.77 0.59 1,760 798 30,410 135.3 29,946 133.2 23,250 103.4 55.5 1410 4
Plate Lip 36 915 0.95 0.73 1,859 843 30,410 135.3 29,946 133.2 23,250 103.4 55.5 1410 4
Ditching 60 1500 0.90 0.69 1,121 508 45,615 202.9 34,400 153.0 24,881 110.7 37.0 940 0
72 1800 1.06 0.81 1,244 564 45,615 202.9 34,400 153.0 24,881 110.7 37.0 940 0
*All capacities are SAE heaped ratings and with side cutters.
230C LC Buckets
A full line of buckets is offered to meet a wide variety of applications. Digging forces are with power boost. The buckets have an adjustable bushing for side clearance, with the exception of the
ditching bucket. Tooth selection includes either the John Deere Fanggs
® , Standard, Tiger, Twin Tiger, Abrasion panel, or Flare tooth, or the ESCO (Vertalok) Standard, Tiger, Twin Tiger, or Flare tooth.
Replaceable cutting edges are available through John Deere parts. Optional side cutters add 6 inches (150 mm) to bucket widths.
Bucket Bucket Bucket Arm Dig Force Arm Dig Force Bucket
Type Bucket Width Capacity* Weight Dig Force 9 ft. 9 in. (2.96 m) 11 ft. 10 in. (3.61 m) Tip Radius No. Teeth
in. mm cu. yd. m 3 lb. kg lb. kN lb. kN lb. kN in. mm
General-Purpose 24 610 0.95 0.73 1,453 659 35,846 159.4 26,710 118.8 23,313 103.7 62.5 1588 3
Plate Lip 30 760 1.20 0.92 1,731 785 35,846 159.4 26,710 118.8 23,313 103.7 62.5 1588 4
36 915 1.48 1.13 1,845 837 35,846 159.4 26,710 118.8 23,313 103.7 62.5 1588 5
42 1065 1.38 1.06 1,785 810 37,670 167.0 27,690 122.9 24,020 106.8 56.5 1435 5
42 1065 1.75 1.34 1,966 892 35,846 159.4 26,710 118.8 23,313 103.7 62.5 1588 5
48 1220 2.03 1.55 2,068 938 35,846 159.4 26,710 118.8 23,313 103.7 62.5 1588 6
Heavy-Duty 30 760 0.95 0.73 1,930 875 37,676 167.0 27,690 122.9 24,020 106.8 56.5 1435 4
Plate Lip 36 915 1.16 0.89 2,075 941 37,676 167.0 27,690 122.9 24,020 106.8 56.5 1435 4
42 1065 1.38 1.06 2,195 996 37,676 167.0 27,690 122.9 24,020 106.8 56.5 1435 5
48 1220 1.60 1.22 2,359 1070 37,676 167.0 27,690 122.9 24,020 106.8 56.5 1435 6
54 1370 1.82 1.39 2,507 1137 37,676 167.0 27,690 122.9 24,020 106.8 56.5 1435 6
Heavy-Duty 24 610 0.92 0.70 1,765 801 35,846 159.4 26,710 118.8 23,313 103.7 62.5 1588 3
High Capacity 30 760 1.20 0.92 2,010 912 35,846 159.4 26,710 118.8 23,313 103.7 62.5 1588 4
36 915 1.48 1.13 2,133 968 35,846 159.4 26,710 118.8 23,313 103.7 62.5 1588 4
42 1065 1.75 1.34 2,279 1034 35,846 159.4 26,710 118.8 23,313 103.7 62.5 1588 5
48 1200 2.03 1.55 2,505 1136 35,846 159.4 26,710 118.8 23,313 103.7 62.5 1588 6
Severe-Duty 36 915 1.16 0.89 1,921 871 39,058 173.7 27,319 121.5 23,777 105.8 54.5 1384 4
Cast Lip 42 1065 1.38 1.06 2,119 961 39,058 173.7 27,319 121.5 23,777 105.8 54.5 1384 5
Severe-Duty 30 760 0.95 0.73 2,080 943 37,676 167.0 27,640 122.9 24,020 106.8 56.5 1435 4
Plate Lip 36 915 1.16 0.89 2,179 988 37,676 167.0 27,640 122.9 24,020 106.8 56.5 1435 4
42 1065 1.38 1.06 2,345 1064 37,676 167.0 27,640 122.9 24,020 106.8 56.5 1435 5
Ditching 60 1525 1.34 1.02 1,562 709 45,273 201.4 29,244 130.1 25,225 112.2 47.0 1194 0
72 1830 1.66 1.27 1,759 798 45,273 201.4 29,244 130.1 25,225 112.2 47.0 1194 0
*All capacities are SAE heaped ratings and with side cutters.
