279815-PTG-D-0408
Johnson Controls Unitary Products 5
SEER = Seasonal Energy Efficiency Ratio - the total cooling output in BTU's during a normal annual usage period for cooling divided by the
total electric power input in watt-hours during the same period.
TABLE 1: PHYSICAL DATA
MODELS
ACP
024 030 036 042 048 060
EVAPORATOR
BLOWER
CENTRIFUGAL BLOWER (Dia. x Wd. in.) 10 x 8 10 x 8 10 x 8 11 x 10 11 x 10 11 x 10
FAN MOTOR HP ½ ½ ½ 1
EVAPORATOR
COIL
ROWS DEEP 2 2 3 3 3 3
FINS PER INCH 15 15 13 16 16 16
FACE AREA (Sq. Ft.) 4.38 4.38 4.38 4.38 5.63 5.63
CONDENSER
FAN
PROPELLER DIA. (in.) 22 22 22 22 22 22
FAN MOTOR HP ¼ ¼ ¼ ¼ ¼ ½
NOM. CFM TOTAL 1,800 1,800 1,800 2,400 3,000 3,000
CONDENSER
COIL
ROWS DEEP 1 1 1 1 1 2
FINS PER INCH 20 20 20 20 20 20
FACE AREA (Sq. Ft.) 12.9 12.9 12.9 12.9 16.4 16.4
CHARGE REFRIGERANT 22 (lbs./oz.) 4/10 5/9 5/0 4/12 6/0 10/8
FILTER FACE AREA (Sq. Ft.) / Qty. / Size 2.14 / 1 / 14" x 22”
COMPRESSOR HERMETIC, QTY. = 1 (Type) Recip. Rotary Scroll Scroll Scroll Scroll
3
4
3
4
TABLE 2: RATINGS - ARI
Model ACP
Cooling 1
Capacity
80/67-95 °F
Sound Rating 2
(decibels)
Electric Heat
Nom. Capacity
KW
(single phase)
Electric Heat
Nom. Capacity
KW
(three phase) MBH SEER
024 24.0 13.00 80 5.0, 7.5, 10.0 N / A
030 29.2 13.00 82 5.0, 7.5, 10.0, 15.0 N / A
036 35.0 13.00 75 5.0, 7.5, 10.0, 15.0 10.0, 15.0
042 42.0 13.00 77 5.0, 7.5, 10.0, 15.0 10.0, 15.0
048 46.0 13.00 82 10.0, 15.0, 20.0, 25.0 10.0, 15.0, 20.0, 25.0
060 58.0 13.00 82 10.0, 15.0, 20.0, 25.0 10.0, 15.0, 20.0, 25.0
1. Certified in accordance with the Unitary Small Equipment certification program, which is based on ARI Standard 210/240.
2. Rated in accordance with ARI Standard 270.
