11 typical wiring diagram (460-3-60 power, Supply) acp models – Johnson Controls ACPU024 THRU 060 User Manual

Page 28

background image

279815-PTG-D-0408

28

Johnson Controls Unitary Products

FIGURE 11 -TYPICAL WIRING DIAGRAM (460-3-60 POWER SUPPLY) ACP MODELS
