279815-PTG-D-0408
16 Johnson Controls Unitary Products
TABLE 8: COOLING CAPACITIES - 5 TON (ACP060)
Air on
Evaporator Coil
Temperature of Air on Condenser Coil
Total
Capacity 1
(MBh)
Total
Input
(kW) 2
Sensible Capacity (MBh) Total
Capacity 1
(MBh)
Total
Input
(kW) 2
Sensible Capacity (MBh)
CFM
WB
(°F) Return Dry Bulb (°F) Return Dry Bulb (°F)
90 85 80 75 70 65 90 85 80 75 70 65
75°F 85°F
1500
77 67.7 4.1 30.6 25.2 19.8 - - - 66.6 4.6 29.8 24.3 18.8 - - -
72 64.0 4.1 40.4 35.0 29.6 24.2 - - 62.2 4.6 39.6 34.0 28.5 23.0 - -
67 60.2 4.1 50.2 44.8 39.4 34.0 28.6 - 57.8 4.5 49.3 43.8 38.3 32.8 27.3 -
62 56.3 4.1 56.3 54.2 48.8 43.4 38.0 32.6 53.7 4.5 53.7 52.6 47.1 41.6 36.1 30.6
57 54.0 4.1 54.0 54.0 52.1 46.7 41.3 35.8 51.8 4.5 51.8 51.8 49.4 43.9 38.4 32.9
1675
77 69.7 4.2 32.6 26.8 20.9 - - - 68.3 4.6 31.9 25.9 20.0 - - -
72 65.8 4.2 43.0 37.1 31.3 25.5 - - 63.8 4.6 42.2 36.3 30.3 24.4 - -
67 61.9 4.1 53.3 47.5 41.7 35.9 30.0 - 59.3 4.6 52.5 46.6 40.6 34.7 28.8 -
62 57.9 4.2 57.9 56.8 51.6 46.2 39.9 34.1 55.1 4.6 55.1 54.5 50.1 44.1 38.2 32.2
57 55.5 4.2 55.5 55.5 55.1 49.7 43.4 37.6 53.1 4.6 53.1 53.1 52.5 46.6 40.6 34.7
1850
77 71.6 4.2 34.6 28.3 22.1 - - - 70.0 4.7 33.9 27.5 21.2 - - -
72 67.6 4.2 45.5 39.3 33.0 26.8 - - 65.4 4.7 44.8 38.5 32.1 25.7 - -
67 63.6 4.2 56.4 50.2 43.9 37.7 31.4 - 60.8 4.7 55.8 49.4 43.0 36.6 30.3 -
62 59.5 4.2 59.5 59.5 54.4 48.9 41.9 35.6 56.4 4.6 56.4 56.4 53.0 46.6 40.2 33.9
57 57.1 4.2 57.1 57.1 58.0 52.8 45.5 39.3 54.4 4.7 54.4 54.4 55.6 49.2 42.8 36.5
1900
72 68.1 4.3 45.7 39.4 33.1 26.8 - - 65.7 4.7 45.2 38.7 32.2 25.7 - -
67 64.1 4.2 56.7 50.4 44.1 37.8 31.5 - 61.1 4.7 56.1 49.6 43.1 36.7 30.2 -
62 60.0 4.3 60.0 60.0 54.5 48.6 41.9 35.6 56.7 4.7 56.7 56.7 53.1 46.7 40.2 33.7
57 57.5 4.3 57.5 57.5 58.0 52.2 45.4 39.1 54.7 4.7 54.7 54.7 55.2 48.8 42.3 35.8
1950
72 68.7 4.3 45.9 39.5 33.2 26.8 - - 66.0 4.8 45.5 38.9 32.3 25.7 - -
67 64.6 4.3 56.9 50.5 44.2 37.8 31.5 - 61.4 4.8 56.5 49.9 43.3 36.7 30.1 -
62 60.4 4.3 60.4 60.4 54.7 48.3 42.0 35.7 57.0 4.7 57.0 57.0 53.3 46.7 40.1 33.5
57 58.0 4.3 58.0 58.0 58.0 51.6 45.3 38.9 54.9 4.7 54.9 54.9 54.9 48.3 41.7 35.1
95°F 105°F
1500
77 65.5 5.0 29.0 23.4 17.8 - - - 62.8 5.6 28.3 22.7 17.1 - - -
72 60.5 5.0 38.7 33.1 27.5 21.9 - - 57.4 5.6 37.6 32.0 26.4 20.8 - -
67 55.5 5.0 48.3 42.7 37.1 31.5 25.9 - 51.9 5.5 46.9 41.3 35.7 30.1 24.5 -
62 51.1 4.9 51.1 51.1 45.5 39.9 34.3 28.7 47.7 5.4 47.7 47.7 43.8 38.2 32.5 26.9
57 49.5 5.0 49.5 49.5 46.8 41.2 35.6 30.0 46.7 5.5 46.7 46.7 44.0 38.4 32.7 27.1
1675
77 66.9 5.1 31.2 25.1 19.1 - - - 64.1 5.7 31.1 24.4 18.3 - - -
72 61.8 5.1 41.4 35.4 29.3 23.3 - - 58.6 5.7 40.5 34.3 28.2 22.1 - -
67 56.8 5.1 51.7 45.7 39.6 33.6 27.5 - 53.0 5.6 49.8 44.3 38.1 32.0 25.9 -
62 52.2 5.0 52.2 52.2 48.5 42.1 36.4 30.4 48.7 5.5 48.7 48.7 46.8 40.4 34.5 28.3
57 50.6 5.0 50.6 50.6 50.0 43.4 37.9 31.8 47.7 5.6 47.7 47.7 47.0 40.6 34.7 28.6
1850
77 68.4 5.2 33.3 26.8 20.3 - - - 65.5 5.8 33.9 26.1 19.4 - - -
72 63.2 5.2 44.2 37.7 31.2 24.7 - - 59.8 5.7 43.3 36.7 30.0 23.3 - -
67 58.0 5.2 55.1 48.6 42.1 35.6 29.1 - 54.1 5.7 52.7 47.2 40.6 33.9 27.3 -
62 53.4 5.1 53.4 53.4 51.6 44.3 38.6 32.1 49.7 5.6 49.7 49.7 49.7 42.7 36.4 29.8
57 51.7 5.1 51.7 51.7 53.1 45.6 40.1 33.6 48.6 5.6 48.6 48.6 50.0 42.8 36.7 30.0
1900
72 63.3 5.2 44.6 38.0 31.3 24.6 - - 59.8 5.8 43.8 37.0 30.2 23.4 - -
67 58.1 5.2 55.6 48.9 42.2 35.5 28.9 - 54.2 5.7 52.9 47.6 40.8 34.0 27.2 -
62 53.4 5.1 53.4 53.4 51.8 44.7 38.4 31.7 49.8 5.6 49.8 49.8 49.4 42.4 35.7 28.9
57 51.8 5.1 51.8 51.8 52.5 45.3 39.1 32.4 48.7 5.7 48.7 48.7 49.3 42.3 35.7 28.9
1950
72 63.4 5.2 45.1 38.2 31.4 24.5 - - 59.8 5.8 44.3 37.3 30.4 23.4 - -
67 58.2 5.2 56.1 49.2 42.4 35.5 28.6 - 54.2 5.8 53.2 48.0 41.1 34.1 27.1 -
62 53.5 5.1 53.5 53.5 51.9 45.1 38.2 31.3 49.8 5.7 49.8 49.8 49.0 42.0 35.1 28.1
57 51.9 5.2 51.9 51.9 51.9 45.0 38.1 31.2 48.7 5.7 48.7 48.7 48.7 41.7 34.7 27.8
