41
Specifications
Supplied accessories Power cable ×1, Speaker unit ×1, Screws for the
speaker unit ×2, remote control unit ×1, AAA
batteries ×2
Input terminals HDMI ×3
D-sub (15 pin) ×1
Audio input (3.5 mm stereo mini jack)
Output terminals Speaker output
External control RS-232C
Dimensions
unit: mm (inch)
1 : 990.0 (39)
2 : 716.8 (28 1/4)
*1 / 689.3 (27 1/8) *2 / 661.8 (26) *3
3 : 400.0 (15 3/4)
4 : 117.0 (4 5/8)
*1 / 89.5 (3 5/8) *2 / 62.0 (2 1/2) *3
5 : 400.0 (15 3/4)
6 : 200.0 (7 7/8)
7 : 42.5 (1 3/4)
8 : 599.8 (23 5/8)
9 : 170.0 (6 3/4)
Notice on transportation
● This monitor is precision equipment and needs dedicated packing
material for transportation. Never use any packing material supplied
from sources other than JVC or JVC-authorized dealers.
*1 At the high position
*2 At the middle position
*3 At the low position
