equipment key
7
Diagram Key
REAR PANEL
1
Mains Power Cord
supplies power to VCR.
2
ANT. IN Connector enables
connection of aerial.
3
L-1 IN/OUT Connector
enables AV connection to TV
or second VCR; input
recordable when L-1 selected.
4
AUDIO OUT (L/R)
Connectors enable connection
of audio cassette recorder, TV
or second VCR for dubbing.
5
RF. OUT Connector enables
connection to aerial terminal
of TV receiver.
VCR DISPLAY PANEL
1
c
Indicator lights when
the c button has been
pressed to engage Timer
mode.
2
Play Indicator lights up
during playback; blinks during
Repeat Playback or when
using Next Function Memory
for playback.
3
Record Indicator lights up
during recording; blinks
during Instant Timer
Recording.
4
Channel Display shows
preset position where the
station currently being
received is stored.
Mode shows external input
mode selected (L-1).
Clock Display shows
current time.
Preset Position* (or Mode)
and Clock Display appear
alternately when b is
pressed.
*
Preset Position (or Mode) is
not displayed during playback.
5
REVIEW Indicator blinks
after timer-recording and
shows how many programmes
have been timer-recorded.
6
VCR Indicator lights when
the VCR is in the video mode.
At this point, the TV automati-
cally enters AV mode.
REMOTE CONTROL
1
TV Button enables Remote
Control of your JVC TV.
2
TV/VCR Button switches
connected TV’s mode between
TV and AV.
3 r
Button
‘reviews’ timer-recorded
programme.
4
Number Keys are used in
preset position selection and
the VIDEO Plus+ Timer
Programming.
5
PDC Button enables/
disables PDC recording.
*
VPS (Video Programme
System) recording is not currently
available in the U.K. and not
possible with this VCR.
6 x
Button cancels timer-
programme.
0000 Button resets
counter on the on-screen
display to ‘0:00:00’.
7
STOP +/– Button inputs
programme Stop Time.
8
START +/– Button
accesses Regular Program
screen; inputs programme
Start Time.
9
PROG Button accesses
VIDEO Plus+ Program screen.
10 C
Button accesses
Program screens/displays to
check the programme that you
have programmed (next
programme’s information
screen appears each time
button is pressed).
11 <
Button — same as
button on VCR.
12 T
Button — same as
button on VCR.
13 S
Button stops tape.
14 m
Button accesses
Menu screen.
15 AB
Buttons are
used for selection in on-screen
menus.
TV PR +/– Buttons selects
the connected JVC TV's
channel.
16
STANDBY/ON o Button
— same as button on VCR.
17
AUDIO Button changes
output sound mode.
(TV Muting) Button
mutes sound of connected JVC
TV.
18 b
(Display) Button —
same as button on VCR
.
19
DAILY Button enables
timer recording of daily
serials.
20
WEEKLY Button enables
timer recording of weekly
serials.
21
AUX Button selects VCR’s
auxiliary input mode.
22 c
Button engages timer-
standby mode.
23
DATE +/– Button inputs
date of programme for timer
recording.
24
PR +/– Button — same as
buttons on VCR.
25
Auto Tracking Button
enables/disables auto
tracking mode during
playback.
/
Button selects tape
speed.
26 3
Button
initiates a 30-second period of
fast-motion playback.
27 .
Button — same as
button on VCR.
28 >
Button — same as
button on VCR.
29 |
Button — same as
button on VCR.
30 O
Button enters
selections made in on-screen
menus.
31 D E
Buttons initiate
functions such as Index
Search, variable-speed search,
frame by frame playback.
TV
+/– Buttons control
volume of connected JVC TV.
FRONT PANEL
1
STANDBY/ON o Button
turns VCR on/off (loading a
cassette also turns power on).
2
Cassette Loading Slot is
where cassette is inserted;
door closes.
3 <
Button rewinds
the tape; initiates high-speed
reverse search.
4 .
Button plays back tape;
cancels Pause, Still, Slow,
Search modes.
5 >
Button fast-
forwards tape; initiates high-
speed forward search.
6
SP/LP Button selects tape
speed.
7 c
Button engages timer
standby mode.
8
Display Panel provides
clear view of various displays
and indicators.
9
Infrared Beam Receiving
Window is where Remote
Control should be aimed when
in use.
10
PR +/– Buttons select a
preset position.
11 b
(Display) Button
switches display between
clock time and Preset
Position* (or Mode).
* Preset Position (or Mode) is not
displayed during playback.
12 T
Button starts regular
recording (press once), Instant
Timer Recording (press twice);
sets duration of ITR.
13 |
Button stops tape
temporarily during recording;
stops tape temporarily during
playback; plays back frame by
frame with each additional
press.
14
§
Button stops tape;
ejects tape during Stop mode.
