ENGLISH
1
Failure to observe what is
mentioned under this symbol
could lead to physical injury and
material damage. Extreme
caution should be exercised.
• Connect the power cord plug to a wall
outlet only after all necessary equipment
has been connected.
Making connections while the power
cord plug is connected to the wall outlet
could result in electric shock.
Failure to observe what is
mentioned under this symbol
could lead to physical injury and
material damage. Extreme
caution should be exercised.
• Do not modify (disassemble) the front
speakers.
This could result in fire or electric shock.
Regarding the “safety precaution” symbols
Various symbols are indicated on the product and in this Installation Manual.
These symbols are provided in order to prevent physical injury and material damage. Be sure you understand the
meaning of the symbols before reading this manual.
SAFETY PRECAUTIONS
WARNING
CAUTION
Explanation of symbols
• This symbol (including a warning) indicates that
CAUTION should be exercised.
• Prohibited actions are indicated by the following symbols.
• Actions that should be performed (compulsory and
instructed actions) are indicated by the following symbol.
General caution
Prohibited
Disassembling
prohibited
General instruction
Names of parts
Front
1 Speaker unit
2 Saran net
This net protects the speaker.
Back
3 Speaker bracket
Attach to the back of the
display.
4 Speaker terminal
Connect this terminal to the
speaker terminal on the
display using the supplied
speaker cords.
Accessories
Check to be sure you have all of the supplied accessories. The number in the parentheses is the quantity of the
pieces supplied. If anything is missing, contact your dealer immediately.
Front speakers (L,R)
Cord clamps (6) Speaker cords
(1.2 m x 2)
Mounting screws (6)
1
2
4
3
