ENGLISH
59
Getting Started
Preparation
Basic Operation
Troubleshooting
Settings
Others
■
PC compatible signals
No. Designation Resolution
fh
[kHz]
fv
[Hz]
Dot CLK
[MHz]
Polarity Total No.
of dots
[dot]
Total No.
of lines
[line]
No. of
effective
dots
[dot]
No. of
effective
lines
[line]
H V
1 VGA 60 640 X 480 31.500 60.000 25.200 - - 800 55 60 80
VGA 59.94 640 X 480 31.469 59.940 25.175 - - 800 55 60 80
SVGA 60 800 X 600 37.879 60.317 40.000 + + 1,056 68 800 600
XGA 60 1024 X 768 48.363 60.004 65.000 - - 1, 806 1,0 68
5 WXGA 60 1280X 768 47.760 60.000 79.998 - + 1,65 96 1,80 68
6 WXGA +60 1440 X 900 55.919 59.999 106.470 - + 1,90 9 1,0 900
SXGA 60 1280 X 1024 63.981 60.020 108.000 + + 1,688 1,066 1,80 1,0
8 WSXGA +60 1680 X 1050 65.222 60.002 147.140 - + ,56 1,08 1,680 1,050
9 WUXGA 60 1920 X 1200 74.038 59.95 154.000 + - ,080 1,5 1,90 1,00
Images may not be displayed if the above timings are not met.
Dimensions
365 236 64.5
225.4
Φ 42
12
95
167
297
477.5
90.6
42.5
105
198
Lens center
Lamp cover
(Unit: mm) ■
Top Surface ■ Bottom Surface
■
Front ■ Back Surface
