82
Rear Projection Television Type
Reception Format
Reception Range
Power Source
Power Consumption
Model AV-65WP94
NTSC, BTSC System (Multi-Channel Sound)
ATSC Terrestrial
VHF 2 to 13, UHF 14 to 69 Sub, Mid, Super, Hyper and Ultra bands
(180 channel frequency synthesizer system)
AC 120V, 60 Hz
320W
Screen Size 65 inch / 165 cm
measured diagonally,
16:9 ratio
Speakers 16 cm round X 2, 5.5 cm round X 2
Audio Output Full Range - 10W + 10W
Antenna Terminal
(VHF/UHF, ATSC IN)
75 ohms (F-type connector x 2)
External Input Jacks
Video: 1 Vp-p, 75 ohms
Audio: 500 mVrms (-4dBs) high impedance
Conponent Input
Jack
Y: 1Vp-p positive, 75 ohms (negative sync provided)
Pb/Pr: 0.7 Vp-p 75 ohms
S-Video Input Jacks
Y: 1Vp-p positive, 75 ohms (negative sync provided)
C: 0.286 Vp-p (burst signal), 75 ohms
AV CompuLink III
Jack
3.5 mm mini jack X 1
Digital–In DVI–D Single Link 19 pin
Note: The Digital–In terminal is not compatible with picture signals of a
personal computer
61 3/4 x 58 7/8 x 28 3/4
156.6 x 149.5 x 72.8
Illuminated remote control unit / AA batteries X 2
Dimensions (in)
W X H X D (cm)
Weight (lbs / kg)
Accessories
Audio Output Jacks
(VARI/FIX)
Vari: More than 0 1000mVrms (+2.2dBs)
FIX: 500mVrms (-4dBs) Low impedance (1000 Hz when modulated 100%)
AV-56WP94
56 inch / 142 cm
measured diagonally,
16:9 ratio
Speaker Input 16 Ohms / 60W (Maximum)
Subwoofer Output
Jack
More than 0 1000mVrms (+2.2dBs)
Low impedance (80 Hz when modulated 100%)
Optical Output
Digital Audio
Digital Out (optical) x 1
iLINK In/Out Jack
TS IN/OUT (4-pin, S400) x 1
IEEE1394 compliant DTCP digital copy protection compatible
53 7/8 x 54 5/8 x 26 3/8
136.8 x 138.6 x 66.7
256 / 116 225 / 102
ATSC Output Video: 1Vp-p, 75ohms
Y: 1Vp-p, 75 ohms
C: 0.286Vp-p (burst signal), 75 ohms
Audio: 250mVrms (-10dBs)
Fs-18dB Low Impedance
Specifications subject to change without notice.
Specifications
