7 Available signals
The following signals are available for this monitor.
Video signals
No. Signal name
Signal format
shown in the
status display
( ☞ page 7)
Input terminal
VIDEO
(INPUT1,
INPUT2)
COMPO./RGB
(Analog
component/
Analog RGB)* 1
E. AUDIO HD/
SD SDI
(IN 1, IN 2)* 2
DVI-D (HDCP)
(Digital component/
digital RGB)
1 NTSC NTSC √ — — —
2 PAL PAL √ — — —
3 B/W50 B/W50 √ — — —
4 B/W60 B/W60 √ — — —
5 480/60i 480/60i — √ √ √
6 480/59.94i 480/59.94i — √ √ √
7 576/50i 576/50i — √ √ √
8 480/60p 480/60p — √ — √
9 480/59.94p 480/59.94p — √ — √
10 576/50p 576/50p — √ — √
11 640*480/60p 640*480/60p — — — √
12 640*480/59.94p 640*480/59.94p — — — √
13 720/60p 720/60p — √ √ √
14 720/59.94p 720/59.94p — √ √ √
15 720/50p 720/50p — √ √ √
16 720/30p 720/30p — √ √ —
17 720/29.97p 720/29.97p — √ √ —
18 720/25p 720/25p — √ √ —
19 720/24p 720/24p — √ √ —
20 720/23.98p 720/23.98p — √ √ —
21 1080/60i 1080/60i — √ √ √
22 1080/59.94i 1080/59.94i — √ √ √
23 1035/60i 1035/60i — √* 3 √ √* 3
24 1035/59.94i 1035/59.94i — √* 3 √ √* 3
25 1080/50i 1080/50i — √ √ √
26 1080/60p 1080/60p — — — √
27 1080/59.94p 1080/59.94p — — — √
28 1080/50p 1080/50p — — — √
29 1080/30p 1080/30p — √ √ √
30 1080/29.97p 1080/29.97p — √ √ √
31 1080/25p 1080/25p — √ √ √
32 1080/24p 1080/24p — √ √ √
33 1080/23.98p 1080/23.98p — √ √ √
34 1080/30psF 1080/60i — √* 3 √* 3 —
35 1080/29.97psF 1080/59.94i — √* 3 √* 3 —
36 1080/24psF 1080/24psf — √ √ —
37 1080/23.98psF 1080/23.98psf — √ √ —
√: Acceptable
—: Not acceptable
* 1 Analog component/analog RGB signals are compatible with G on sync signal, Y on sync signals, and composite sync
signals (C S ). The separate sync signal (HS/VS) is not compatible.
* 2 Compatible with EMBEDDED AUDIO signals
* 3 The signal is recognized as 1080/60i, 1080/59.94i.
Computer signals (preset)
DVI-D (HDCP) terminals
No. Signal name
Resolution Frequency
Scan system
Horizontal Vertical Horizontal (kHz) Vertical (Hz)
1 VGA60 640 480 31.5 59.9 Non-interlace
2 WVGA60 852 480 31.5 59.9 Non-interlace
3 SVGA60 800 600 37.9 60.3 Non-interlace
4 XGA60 1024 768 48.4 60.0 Non-interlace
5 WXGA (1280) 1280 768 47.8 60.0 Non-interlace
6 WXGA+60 1440 900 55.9 60.0 Non-interlace
7 SXGA60 1280 1024 64.0 60.0 Non-interlace
8 WSXGA+60 1680 1050 65.2 60.0 Non-interlace
9 UXGA60* 4 1600 1200 75.0 60.0 Non-interlace
10 WUXGA60* 4 1920 1200 74.0 60.0 Non-interlace
11 720/60p 1280 720 45.0 60.0 Non-interlace
12 1080/60p* 4 1920 1080 67.5 60.0 Non-interlace
13 720/50p 1280 720 37.5 50.0 Non-interlace
14 1080/50p* 4 1920 1080 56.25 50.0 Non-interlace
* 4 For DT-V20L3DY: When No. 9, 10, 12 or 14 signals come in, thin lines will become obscured because their signal
resolution is higher than the screen resolution.
• Non-preset signals may not be displayed normally even if their frequency is within the acceptable range ( ☞
“Horizontal/vertical frequency (computer signal)” on page 21).
• When a preset signal comes in, the signal format is shown on the status display. For other signals, the
resolution is shown.
Specification of the DVI-D (HDCP) terminal
Connect it to the DVI-D output terminal on a personal computer.
Pin No. Input signal Pin No. Input signal Pin No. Input signal
1 T.M.D.S Data 2– 9 T.M.D.S Data 1– 17 T.M.D.S Data 0–
2 T.M.D.S Data 2+ 10 T.M.D.S Data 1+ 18 T.M.D.S Data 0+
3 T.M.D.S Data 2 shield 11 T.M.D.S Data 1 shield 19 T.M.D.S Data 0 shield
4 NC 12 NC 20 NC
5 NC 13 NC 21 NC
6 DDC Clock 14 +5 V Power 22 T.M.D.S Clock shield
7 DDC Data 15 GND 23 T.M.D.S Clock+
8 NC 16 Hot Plug Detect 24 T.M.D.S Clock–
