RS-232C INTERFACE
CTL Data Sense For acquiring lapse counter of selected deck in hours, minutes and seconds.
E.g.: When time lapse counter is 1 hr 23 min 45 sec.
JVC Data Sense
1st Byte 2nd Byte 3rd Byte 4th Byte 5th Byte 6th Byte 7th Byte 8th Byte
CTL Data Sense Hr (Tens) Hr (Ones) Min (Tens) Min (Ones) Sec (Tens) Sec (Ones) Frame
(Tens)
Frame
(Ones)
D9 3* 3* 3* 3* 3* 3* 3* 3*
E.g. (01:23:45) 30 31 32 33 34 35 30 30
DD JVC
SENSE
1byte 2byte 3byte 4byte
DV HDD/DVD DV HDD/DVD DV HDD/DVD DV HDD/DVD
bit7 1 (Fixed) 1 (Fixed) 0 (Fixed) 0 (Fixed) 1 (Fixed) 1 (Fixed) 1 (Fixed) 1 (Fixed)
bit6 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed) 1 (Fixed) 1 (Fixed)
bit5 0 (Fixed) 0 (Fixed) 1 (Fixed) 1 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed)
bit4
During
Playback of LP
Recorded Tape
0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed)
bit3 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed)
During
dubbing
(Including
PAUSE) During
dubbing
(Including
PAUSE)
bit2 0 (Fixed) 0 (Fixed) 0 (Fixed) 0 (Fixed)
During Audio
Dub (Including
PAUSE)
0 (Fixed) 0 (Fixed) 0 (Fixed)
bit1 0 (Fixed) 0 (Fixed) 1 (Fixed) 1 (Fixed)
During Insert
(Including
PAUSE)
0 (Fixed) 0 (Fixed) 0 (Fixed)
bit0 1 (Fixed) 1 (Fixed) 0 (Fixed) 0 (Fixed)
During dubbing
(Including
PAUSE) During dubbing
(Including
PAUSE)
0 (Fixed) 0 (Fixed)
