Jims USA Twin Cam Racekit Box 1 1208-1351 User Manual
Page 5
555 Dawson Drive, Camarillo, CA 93012 Phone 805-482-6913 • Fax 805-482-7422
4
Rev I
9-12
No.1208-1351
A Division of Thiessen Products, INC
IIn
ns
st
tr
ru
uc
ct
tiio
on
n S
Sh
he
ee
et
t F
Fo
or
r B
Bo
ox
x 1
1 1
12
20
0”
”,, 1
13
31
1”
”,, o
or
r 1
13
35
5”
”
E
En
ng
giin
ne
e A
As
ss
se
em
mb
bl
liie
es
s O
Or
r E
En
ng
giin
ne
e R
Ra
ac
ce
e K
Kiit
ts
s
B
Bo
ox
x O
On
ne
e E
En
ng
giin
ne
e R
Ra
ac
ce
e K
Kiit
t
IIn
ns
st
ta
al
ll
la
at
tiio
on
n IIn
ns
st
tr
ru
uc
ct
tiio
on
ns
s
Inspection of parts for box 1
Fig.3 - Box 1 components - See Page 9
Note: Please verify contents of box 1 and complete
inspection of these parts prior to proceeding with
installation as listed on page 9. Please contact
JIMS
®
Tech Support (805-482-6913) if there are
any issues with the parts enclosed. See Fig.3 and
page 4.
Lower End Assembly Inspection
• Read and remove Red Tag attached to the plas-
tic bag containing the lower end.
• Cut open the protective plastic bag, and with
the help of a friend carefully remove the lower
end from the box and place it into your engine
stand.
• Refer to the manufacturer’s instructions included with your engine stand for proper installation.
• Replace the blue foam rod protectors into cylinder spigot bore (prevents rod from knocking in case).
• Remove masking intended for cleanliness as indicated.
• Check case finish for scratches may have resulted from shipping.
• Cover lower end assembly with the supplied clean clear plastic bag
Cylinder Studs
•
You will find eight (8) cylinder studs. Two (2) short studs and six (6) long studs.
•
Verify presence of green loctite 620 for use when installing the cylinder studs.
Fig.3 - Box 1 components - See Pages 9
For “A” Engine, 99-06 FL,
99-05 FXD
Part No. 1286-1346 (Black)
Part No. 1286-1345 (Silver)
For “B” Engine, 06 FXD,
& 07 FL to Pres
Part No. 1486-1835
