BOX 1 Materials Check-Off Sheet
PART NO.
H-D® NO.
DESCRIPTION
QTY.
1290-1309
120” Lower End Assembly (Black) “A” 1999-Pres. FL, 99-05 FXD
1
1290-1315
120” Lower End Assembly (Sliver) “A” 1999-Pres. FL, 99-05 FXD
1
1390-1309
131” Lower End Assembly (Black) “A” 1999-Pres. FL, 99-05 FXD
1
1390-1315
131” Lower End Assembly (Sliver) “A” 1999-Pres. FL, 99-05 FXD
1
1490-1309
120” Lower End Assembly (Black) “B” 2000-2006 FXST
1
1490-1315
120” Lower End Assembly (Sliver) “B” 2000-2006 FXST
1
1690-1309
120” Lower End Assembly (Black) 06-Pres. FXD, 07 to Pres. FLH
1
1690-1315
120” Lower End Assembly (Sliver) 06-Pres. FXD, 07 to Pres. FLH
1
1708-1309
131” Lower End Assembly (Black) 06-Pres. FXD, 07 to Pres. FLH
1
1708-1315
131” Lower End Assembly (Sliver) 06-Pres. FXD, 07 to Pres. FLH
1
135" Lower End Assembly (Black) "A"
1
135" Lower End Assembly (Silver) "A"
1
1286-1319
24038-99A
Spacer, Sprocket Shaft “A” 99-05 FXD also “B” 2000 FXST.
1
1486-1834
24039-99A
Spacer, Sprocket shaft “B”, 2001-2006 FXST
1
1286-1320
24008-99A
Spacer, Sprocket Shaft 99-Pres. FLH,06-Pres.FXD, 07-Pres. FXST
1
1286-1346 26261-99
Oil Filler Mount Kit (Black) “A” 99-07 FL, 99-05 FXD
1
1286-1345
26274-99
Oil Filler Mount Kit (Silver) “A” 99-06 FL, 99-05 FXD
1
1486-1835 26352-95A
Adapter, Oil Filler “B” 2000-Pres. FXST, 06-Pres.FXD, 07-Pres.FL
1
1286-1360
Cylinder Stud (Long) “A”& “B”
6
1286-1361
Cylinder Stud (Short) “A”,&“B”
2
1286-1362
Loctite Retaining Compound #.620 .02oz “A”&“B”
2
1286-1387
Stud Installer Tool “A”,& “B”
1
1286-1395
Bag. 24X24 (To Cover Engine”B”)
1
1286-1394
Zip Tie, Motor Bagging ,“A”,&“B”
1
1208-1302
Red Tag, Engine info “A”, & “B”
1
1286-1331
16478-85A
Screw, Internal Thread, 3-3/16” “A”,& “B”
4
1286-1332 16480-92
Screw, Internal Thread, 1-7/8”,“A”,& “B”
4
1208-1304
Warranty Sheet “A”,& “B”
1
1286-1330
Moly Lube (For Headbolts)
1
