Introduction
Safety Precautions .................................... 3
Characteristics .......................................... 5
Table of Contents ...................................... 6
Precautions for proper use of this product ... 7
Name of Parts ........................................... 9
Setting the Switches and the Lens
(TK-C215VP4U/E) ................................ 12
Setting the Switches and the Lens
(TK-C215VP12U/E) .............................. 14
System Example ..................................... 16
About Connection Cables ....................... 17
Video signal cables ............................. 17
DC 12 V or AC 24 V
power supply cable ......................... 17
Alarm Input Terminals ..................... 18
The right sequence to connect and set the
camera ................................................. 19
Setting the switches ................................ 20
Mounting the base .................................. 21
Cable Connection ................................... 22
Mounting the camera unit ....................... 23
Adjusting the video image ...................... 25
Mounting the inner dome ........................ 30
Mounting the dome cover ....................... 30
Mounting the camera using
the electrical box .................................. 31
Mounting the camera using the pipe ...... 32
White-spot correction .............................. 34
Specifications ......................................... 36
Table of Contents
ⅷ Before starting an important recording, be
sure to perform a test recording in order to
confirm that a normal recording is possible.
ⅷ We will not provide any compensation
whatsoever for the contents to be recorded or
loss of opportunities when recording is not
properly performed due to malfunction of the
video camera, VTR, hard disk recorder or
video tape.
ⅷ Before touching the camera unit, make sure
to touch the metal surface of the [MONITOR]
terminal to discharge any static electricity
from your body. Static electricity may cause
the camera to malfunction.
