Jonsered LT2113 User Manual
Page 8
7
1
532 17 46-19
Chassis
2
532 17 65-54
Drawbar
5
532 15 52-72
BumperHood/Dash
9
532 19 48-22
Dash
10
872 14 06-08
Bolt, Carriage 3/8-16 x 1
11
532 17 49-96
Dashboard, Panel LH
13
532 18 69-52
Dashboard, Panel RH
17
532 18 67-07
Hood Pnt
18
532 18 49-21
BumperHood
24
874 78 06-16
Bolt, Hex Head, Fin. 3/8-16 x 1 Gr. 5
25
819 13 13-12
Washer 13/32 x 13/16 x12 Ga.
26
873 80 06-00
Nut Lock Hex w/Ins. 3/8-16 unc
28
532 18 67-06
Grille
29
532 18 58-46
Lens
30
532 19 57-70
Fender
31
532 13 66-19
Fender Bracket
33
532 18 11-93
Footrest, LH
34
532 18 11-94
Footrest, RH
35
872 11 06-06
Bolt 3/8-16 X 3/4
37
817 49 05-08
Screw Thdrol 5/16-18 x 1/2
38
532 17 57-10
Bracket Asm. Pivot Mower Rear
39
532 40 78-07
Bracket Pivot Laser/Elite
64
532 15 47-98
Dash Lower
142 532 17 57-02
Plate Reinforcement
145 532 40 91-67
Rod Pivot Chassis/Hood
205 817 49 06-08
Screw Thdrol 3/8-16 x 1/2
207 817 67 05-08
Screw Thdrol 5/16-18 x 1/2
208 817 67 06-08
Screw Thdrol 3/8-16 x 1/2
209 817 00 06-12
Screw Hexwsh Thdr 3/8-16 x 3/4
212 532 18 35-50
Insert Lens Reflective
278 532 41 63-58
Screw #10 x 0.750
- -
532 00 54-79
Button Plug
KEY PART
NO. NO.
DESCRIPTION
NOTE: All component dimensions given in U.S. inches.
1 inch = 25.4 mm.
TRACTOR - - MODEL NO. LT2113 (96011026604), PRODUCT NO. 960 11 02-66
CHASSIS AND ENCLOSURES 39
39
