Jonsered LT2113 - Manual (Page 12)

11
1 532 18 67-80 Wheel Steering Opp. Sears Blk
2 532 41 81-68 Axle Asm
3 532 16 98-40 Spindle Asm LH
4 532 16 98-39 Spindle Asm RH
5 532 12 49-31 Bearing Race Thrust Harden
6 532 12 17-48 Washer 25/32 x 1-5/8 x 16 Ga.
7 819 27 20-16 Washer 27/32 x 1-1/4 x 16 Ga.
8 812 00 00-29 Ring Klip #t5304-75
9 532 12 49-37 Bearing Col Strg Blk
10 532 17 51-21 Link Drag
11 810 04 06-00 Washer Lock Hvy Hlcl Spr 3/8
13 532 13 65-18 Spacer Brace Axle
15 873 90 06-00 Nut Lock Flg. 3/8-16 unc
17 532 19 07-53 Shaft Asm Strg
26 532 12 68-47 Bushing Link Drag Blk LR
28 819 13 14-16 Washer 13/32 x 7/8 x 16 Ga.
29 817 00 06-12 Screw 3/8-16 x .75
30 876 02 04-12 Pin Cotter 1/8 x 3/4 Cad
32 532 19 27-57 Rod Tie Wire Form 19 75 Mech
34 810 04 05-00 Washer Lock Hvy Hlcl Spr. 5/16
36 532 15 50-99 Bushing Strg Nat .623/.618Id
37 532 15 29-27 Screw TT #10-32 x 5 x 3/8 Flange
38 532 19 29-16 Cap Wheel Steer P/L
39 819 11 38-12 Washer 11/32 x 2-3/8
40 873 54 06-00 Nut Crownlock 3/8-24
41 532 18 67-37 Adaptor Wheel Strg
42 532 16 96-33 Boot Shaft Steering
43 532 12 17-49 Washer 25/32 x 1 1/4 x 16 Ga.
44 532 19 07-52 Extension Steering
46 532 12 12-32 Cap Spindle Fr Top Blk
65 532 41 47-36 Spacer Brace Axle
67 872 11 06-18 Bolt RDHD SQ 3/8-16 unc x 2-1/4
68 532 16 98-27 Brace Axle
71 532 17 51-46 Steering Asm
82 532 19 99-78 Bracket Susp. Chassis Front
88 532 17 51-18 Bolt Shoulder 7/16-20
91 532 17 55-53 Cup Steering
95 532 18 89-67 Washer Hardened
97 532 42 89-82 Bolt Fin Hex 5/16-18 unc x 4 w/Patch
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches.
1 inch = 25.4 mm.
TRACTOR - - MODEL NO. LT2113 (96011026604), PRODUCT NO. 960 11 02-66
STEERING ASSEMBLY 41
