J-200 Series
9.0 Control Functions
9.1 Control panel
A. leD Display: Can
display current water
temperature (de-
fault display), water
temperature set point,
selected filtration/
heating mode, and
error messages.
B. Heat Indicator: Lit when heater is on.
C. Jets 1 Button: Turns jets pump #1 on and off. Press once for low
speed; press a second time for high speed; press a third time to turn
pump off.
D. Jets 2 Button: Turns high-speed jets pump #2 on and off. Press
once to turn pump #2 on; press a second time to turn pump #2 off.
E. light Button options:
With standard incandescent light: Turns underwater light on and off. •
With optional LED lighting system: Turns underwater light and top •
rim accent lights on in one of three random modes or one of seven
solid colors. Refer to Section 10.4 (page 27) for details.
F. warmer ( ) Button: Increases water temperature set point.
G. Cooler ( ) Button: Decreases water temperature set point.
operation Details
Temperature Adjustment: 65 to 104 °F (18 to 40 °C). Factory default •
setting is 100 °F (38 °C).
Standard light system: Incandescent light runs for 1 hour, then •
automatically shuts off for increased bulb life.
Optional LED light system: All LED lights run for 1 hour, then •
automatically shut off.
Jets 1/Jets 2 Button Operation: Jets run for 20 minutes when •
activated, then turn off automatically to conserve energy. Simply
press either jets button to continue operation for an additional 20
minutes.
1
2
A
B
C
D
E
G
F
24
