35
XV-N510B/XV-N512S/GNT0055-001A/English
C
h
a
n
g
in
g
t
h
e
i
n
it
ia
l
s
e
tt
in
g
s
DELAY
You can set the speaker delay time according to your speakers.
See page 36 for how to set the speaker delay time.
LEVEL
You can set the speaker output level according to your speakers.
See page 36 for how to set the speaker output level.
NOTE
If you connect the player’s digital output to an external Dolby
Digital or DTS decoder, and set [DIGITAL AUDIO OUTPUT] in
the [AUDIO] preference display to [STREAM/PCM], the above
settings are not effective.
Make the speaker settings of the external decoder properly.
OTHERS menu
RESUME
You can select the resume playback mode.
See page 14 for details about the resume playback function.
Setting options
ON, OFF, DISC RESUME
[ON]: when selected, the player can resume playback of the disc
from the position where playback was last interrupted, if the
disc is still in the disc tray.
[OFF]: when selected, the resume function is deactivated.
[DISC RESUME]: when selected, the player can resume
playback of the last 30 discs played. The player retains a
memory of the interrupted positions of the last 30 discs played,
even though they have been removed from the disc tray.
ON SCREEN GUIDE
The player can display “on-screen guide” icons or characters on
the picture, which show what is happening to the disc or the
player.
Example of “on-screen guide” icons:
,
,
Setting options
ON, OFF
[ON]: when selected, the on-screen guide is activated.
AUTO STANDBY
When the player is stopped for more than 30 minutes or 60
minutes, the player enters standby mode automatically.
Setting options
60, 30, OFF
AV COMPULINK MODE
You must set this item correctly to use the AV COMPU LINK
system.
Setting options
DVD1, DVD2, DVD3
• See page 39 for details about the AV COMPU LINK function.
PARENTAL LOCK
When this option is selected, pressing ENTER on the remote
control unit brings up the PARENTAL LOCK display shown below.
This allows you to restrict children from playing DVD VIDEO
discs.
• See page 37 for details about the parental lock setting.
Making fine tuning for your speakers
You can make fine tuning to match your speaker system.
Preparation
Set [ANALOG OUT] in the [AUDIO] preference display to
[MULTI CHANNEL] and [MODE] in the [SPK.SETTING]
preference display to [EXPERT].
To set the speaker sizes and the BASS
REDIRECT function
1
Bring up the SPK.SETTING menu.
2
Press
5/∞ to move
to [SIZE] and press
ENTER.
The [SIZE] display page appears on the TV screen.
3
Press
5/∞ to select the speaker to be set and
press ENTER.
FRONT SPEAKER:
front speakers
CENTER SPEAKER:
center speakers
SURROUND SPEAKER: surround (rear) speakers
4
Press
5/∞ to select the size and press
ENTER.
LARGE: large speaker(s) which can fully reproduce the low-
frequency range.
SMALL: small speaker(s) which cannot fully reproduce the
low-frequency range.
NONE: no speaker(s) connected.
5
Repeat steps 3 and 4 if you want to set other
speakers.
When you use the small speakers which do not fully
reproduce the low-frequency range, you can boost up the
low-frequency signal of the subwoofer or front speakers by
setting the BASS REDIRECT function.
To set the BASS REDIRECT function, go to step 6.
6
Press
5/∞ to select [BASS REDIRECT] and
press ENTER.
7
Press
5/∞ to select [SUB WOOFER] or
[FRONT L/R] and press ENTER.
SUB WOOFER: The low-frequency signal fed from the
subwoofer output is boosted up.
FRONT L/R: The low-frequency signals fed from the front
speaker outputs are boosted up. No audio is output from
the subwoofer.
To return to the [SPK.SETTING] page
Press
5/∞
to move
to [RETURN] and press ENTER.
NOTES
• The [BASS REDIRECT] setting is effective only when at least
any one of the speaker sizes is set to [SMALL].
• No audio is output from the SUBWOOFER jack when [FRONT
L/R] is selected.
• If the front speaker size is set to [SMALL], the [BASS
REDIRECT] setting is fixed to [SUBWOOFER].
• During playback of a DVD AUDIO, audio signal may not be
output correctly depending on the conditions of the player or the
disc itself.
SELECT
ENTER
USE
5∞ TO SELECT, USE ENTER TO CONFIRM
TO EXIT, PRESS SETUP.
SET LEVEL
NONE
PASSWORD
_ _ _ _
PARENTAL LOCK
EXIT
COUNTRY CODE
US
SELECT
ENTER
USE
5∞23 TO SELECT, USE ENTER TO CONFIRM
TO EXIT, PRESS SETUP.
FRONT SPEAKER
LARGE
RETURN
SIZE
CENTER SPEAKER
SMALL
SURROUND SPEAKER
SMALL
BASS REDIRECT
SUB WOOFER
