Back view, Introduction – IOGear GCS1762 User Manual
Page 10
Back View
1. Firmware Upgrade port
The included Firmware Upgrade cable that
transfers the firmware upgrade data from the
administrator’s computer to the GCS1762/
GCS1764 plugs into this connector.
2. USB Hub ports
Plug your USB peripherals (printers, scanners,
etc.) into these ports
3. Console ports
Connect the cables from DVI monitor and
speakers to these ports.
4. CPU ports
The cables included with KVM switch plug into
here and the other end to your computers.
5. Power Jack
The power adapters plugs into this jack.
1
2
3
4
5
