ZT8101 User’s Guide 69
Using the Telnet Console
To configure static IP routes
1. From the Main Menu, select Forwarding | Static/Default Routes and press Enter.
2. Toggle the Action field to Add and configure these fields.
3. Highlight APPLY and press Enter.
4. To delete a route, toggle the Action field to Delete, enter the route information in the fields,
highlight APPLY, and press Enter.
To configure static ARP
The ARP table maps an IP address to a device’s MAC address.
1. From the Main Menu, select Forwarding | Static ARP and press Enter.
2. Toggle the Action field to Add/Modify and configure these fields.
3. Highlight APPLY and press Enter.
4. To delete an entry, toggle the Action field to Delete, enter the entry’s information in the fields,
highlight APPLY, and press Enter.
IP Address Filtering
You can manually configure the switch to drop packets from specified MAC and IP addresses. For
information about specifying MAC addresses to drop, see the Forwarding | Unicast MAC
Address Setting screen.
To specify an IP address for filtering
1. From the Main Menu, select Filtering | IP Address Filtering and press Enter.
2. Toggle the Action field to Add/Modify.
Field Description
IP Address Specifies the IP address to be statically entered into the IP forwarding table.
Subnet Mask Specifies the corresponding subnet mask for the IP address.
Gateway IP
Specifies the address of the next hop gateway for the IP address. This is
usually a router with a connection to a WAN or the Internet.
Metric
Specifies the Routing Information Protocol (RIP) metric. This is the number
of hops between the IP address and the Gateway. This is a number
between 1 and 15.
Field Description
Interface Name
Specifies the IP interface of the IP address that you are adding to the static
ARP table.
IP Address Specifies the IP address of the end node or station.
MAC Address Specifies the MAC address corresponding to the IP address.
