Invacare AX3 - Manual (Page 39)

Elevating Legrest Support Assemblies - ELRSS
NOTE: Legrest Support does not include Legrest Pad.
Item
Number Part Number Description Note
Quantity Per
Package Assembly
Screw, Socket Button Head (M6 x .8 x 25mm) 1 4 47
Washer, Nylon (1/4 x 1/2 x 1/32") 1 1 48
Bracket, Swing, Female 1 1 49
Spring, Compression Swing 1 1 50
Block, Sector 1 1 51
Locknut (M5 x .8) 1 5 52
Locknut (1/4-28) 1 1 53
Bracket, Swing, Male 1 1 54
Nut, Low Cap (5/16"-24) 1 1 55
Bolt, Lug (5/16-24 x 1-3/8") 1 1 56
Screw, Socket Button Head (1/4-28 x 1-1/4") 1 1 57
Plug, Insert (7/8") 1 1 58
Locknut (1/4-20) 1 1 59
Pivot, Footrest 1 1 60
Spacer (5/16 x 1/2 x 3/16") 1 1 61
Tube, Legrest Support, Sector, Color - Right 1 1 62
8881147725 NLA - Legrest Support Tube Assembly, Sector,
Color - Left 1 1 41 B
Screw, Socket Button Head (1/4-20 x 1-3/4") 1 1 42
Plug Button (1") 1 1 43
Screw, Socket Button Head Cap (M6 X .8 X 25mm) 1 1 44
Bushing, Handle 1 1 45
Handle, Release, Black - Left 1 1 46
Screw, Socket Button Head (M6 x .8 x 25mm) 1 4 47
Washer, Nylon (1/4 x 1/2 x 1/32") 1 1 48
Bracket, Swing, Female 1 1 49
Spring, Compression Swing 1 1 50
Block, Sector 1 1 51
Locknut (M5 x .8) 1 5 52
Locknut (1/4-28) 1 1 53
Bracket, Swing, Male 1 1 54
Nut, Low Cap (5/16"-24) 1 1 55
Bolt, Lug (5/16-24 x 1-3/8") 1 1 56
Screw, Socket Button Head (1/4-28 x 1-1/4") 1 1 57
Plug, Insert (7/8") 1 1 58
Locknut (1/4-20) 1 1 59
Pivot, Footrest 1 1 60
Spacer (5/16 x 1/2 x 3/16") 1 1 61
Tube, Legrest Support, Sector, Color - Left 1 1 62
1151418 Legrest Kit, Pivot 1 1 63 C
Screw, Socket Button Head (1/4-20 x 1-3/4") 1 1 64
Locknut (1/4-20) 1 1 65
Pivot, Footrest 1 1 66
1130753 Kit, Pivot Slide Tube Attaching Hardware 1 1 67 D
38
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 07-076
