Axles and Axle Mounting Plate Hardware
Item
Number
Part Number
Description
Note
Quantity Per
Package Assembly
1430177
Axle, Quick Release Assembly, Spoked
1
1
1
A
Screw, C-Sunk Head (M6 x 1 x 40mm)
2
1
2
Plate, Axle, Quick Release
2
1
3
Axle, Quick Release
2
1
4
Lug, Axle
2
1
5
Washer (.250 x .562 x .065/036)
2
1
6
Washer, Serrated (M20.3 x 30mm x 1.5mm)
2
1
7
Nut (3/4-16)
2
1
8
Locknut (M6 x 1)
2
1
9
1430182-NLA
NLA - Axle, Fixed Assembly, Composite
1
1
10
B
Screw, C-Sunk Head (M6 x 1 x 40mm)
2
1
4
Plate, Axle, Fixed
2
1
6
Screw, Hex (M12 x 1.75 x 115mm)
2
1
8
Washer (M22 x 12mm x 2.5mm)
2
1
11
Nut, Hex (M12 X 1.75)
2
1
12
Spacer (12.2MM x 20 x 25.4mm)
2
1
13
Locknut (M6 x 1)
2
1
14
1151399-NLA
NLA - Axle Kit, Fixed Spoke
1
1
15
C
Screw, Hex (M12 x 1.75 x 115mm)
2
1
11
Spacer (12.2MM x 20 x 25.4mm)
2
1
12
Washer (M22 x 12mm x 2.5mm)
2
1
13
Nut, Hex (M12 X 1.75)
2
1
14
A - Includes items 2-9.
B - Includes items 4-6 and 11-14. Item #5 Axle Plate surface coating changed from colorless to a champagne color as of
11/16/09.
C - Includes items 11-14.
NOTE:
18
