Intel Desktop Boards D845GRG and D845GBV Product Guide
50
Primary/Secondary IDE Master/Slave Submenus
Maintenance Main Advanced Security Power Boot Exit
PCI Configuration
Boot Configuration
Peripheral Configuration
IDE Configuration ➜ Primary IDE Master
Diskette Configuration Primary IDE Slave
Event Log Configuration Secondary IDE Master
Video Configuration Secondary IDE Slave
USB Configuration
Chipset Configuration
There are four IDE submenus: Primary master, primary slave, secondary master, and secondary
slave. Table 14 shows the format of these IDE submenus. For brevity, only one example
is shown.
Table 14. Primary/Secondary IDE Master/Slave Submenus
Feature Options Description
Drive Installed None Displays the type of drive installed.
Type
• Auto (default)
• User
Specifies the IDE configuration mode for IDE devices.
Auto fills-in capabilities from ATA/ATAPI device.
User allows capabilities to be changed.
Maximum Capacity None Displays the capacity of the drive.
LBA Mode Control
(Note)
None Specifies LBA mode control.
Block Mode
• Disabled
• 2 Sectors
• 4 Sectors
• 8 Sectors
• 16 Sectors (default)
Specifies number of sectors per block for transfers from
the hard disk drive to memory.
Check the hard disk drive’s specifications for optimum
setting.
PIO Mode
(Note)
• Auto (default)
• 0
• 1
• 2
• 3
• 4
Specifies the PIO mode.
Ultra DMA
• Disabled (default)
• Mode 0
• Mode 1
• Mode 2
• Mode 3
• Mode 4
• Mode 5
Specifies the Ultra DMA mode for the drive.
Cable Detected (Note) None Displays the type of cable connected to the IDE
interface: 40-conductor or 80-conductor (for
ATA-66/100 devices).
Note: These configuration options appear only if an IDE device is installed.
