General
Product code E10G42AFDA
Connectors SFP+ connectors
Cabling • SFP+ direct attached cable
(twinaxial) only
• Other SFP+ optics are not allowed
and cannot be used with this adapter
Adapter Product Features
Intel® PROSet Utility • For easy configuration and
management
Intel® lead-free 4 technology •
Plug and play specification support Standard
Intel® I/OAT 2 including QuickData •
Ships with full-height bracket installed,
low-profile bracket added in package
•
RoHs 3 •
Receive-side scaling •
VMDq 1 In a virtualized environment, packets
dedicated to different virtual machines
can be routed to different queues, thus
easing the routing of these packets to
the target machine
Advanced packet filtering (per port) • 16 exact-matched packets
(unicast or multicast)
• 4096-bit hash filter for
multicast frames
• Promiscuous (unicast and multicast)
transfer mode support
• Optional filtering of invalid frames
Direct Cache Access (DCA) The I/O device activates a pre-fetch
engine in the CPU that loads the data
into the CPU cache ahead of time,
before use, eliminating cache misses
and reducing CPU load
Network Management
DMI 2.0 support, Windows Management
Instrumentation (WMI) and SNMP
•
Remote Installation Services (RIS) •
PXE 2.0 enabled through boot Read-Only
Memory (ROM)
•
Network Operating Systems (NOS) Software Support
Microsoft Windows* 2003 Server IA32, X64
Microsoft Vista* IA32, X64, IPF
Windows Virtual Server* 2005 IA32, X64, IPF
Red Hat Linux* 2.6x or later IA32, X64, IPF
SUSE SLES 10* or later, Professional 9.2
or later
IA32, X64, IPF
FreeBSD* 5.x or later IA32, X64, IPF
ESX 3.x* support (for VMware) IA32, X64, IPF
Fedora* IA32, X64, IPF
EFI 1.1* IA32, X64, IPF
Intel Backing
Limited lifetime warranty •
90-day, money-back guarantee
(U.S. and Canada)
•
Advanced Software Features
Adapter Fault Tolerance (AFT) •
Switch Fault Tolerance (SFT) •
Adaptive Load Balancing (ALB) •
Teaming support •
IEEE 802.3ae* 5 •
Test switch configuration Tested with major switch original
equipment manufacturers (OEMs)
PCIe Hot Plug*/Active Peripheral
Component Interconnect (PCI)
•
IEEE 802.1Q* VLANs •
IEEE 802.3 2005* flow control support •
Tx/Rx IP, TCP, & UDP checksum 0 offloading
(IPv4, IPv6) capabilities control protocol (TCP),
user datagram protocol (UDP), Internet
protocol (IP)
•
IEEE 802.1p* •
TCP segmentation/large send offload •
MSI-X supports Multiple Independent Queues •
Interrupt moderation •
IPv6 offloading Checksum and segmentation capability
extended to new standard packet type
Technical Features
Data rate supported per port 10 Gigabit
Bus type PCI Express 2.0 (2.5 GT/s)
Bus width x8 lane PCI Express, operable in x4, 6 x8
and x16 slots
Bus speed (x8, encoded rate) 20 Gbps uni-directional; 40 Gbps
bi-directional
Interrupt levels INTA, INTB, INTC, INTD
Hardware certifications FCC B, UL, CE, VCCI, BSMI, CTICK, MIC
Controller-processor Intel® 82598EB
Typical power consumption • 12.2 W maximum power, 10.1 W
typical power
• PCI Express +3.3 V power supply –
consumes 2.3 A max, 1.7 A typical
• PCI Express +12 V power supply –
consumes 0.4 A max, 0.4 A typical
Airflow 150 LFM (Linear Feet per Minute)
Operating temperature 0° C to 55° C (32° F to 131° F) with
100 LFM forced airflow (linear feet
per minute)
Storage temperature -40° C to 70° C (-40° F to 158° F)
Storage humidity 90% non-condensing relative humidity
at 35° C
LED Indicators LINK (solid) and ACTIVITY (blinking)
Physical Dimensions
Length 16.74 cm (6.59 in)
Width 6.89 cm (2.71 in)
Height of end bracket PCI Express standard, 12 cm (4.725 in)
PCI Express low-profile, 7.92 cm (3.12 in)
Specifications
