1120 CPU Card and System Board
Card
Battery Pack (1020)
Insulator Sheet (1025)
Diskette Drive / CD-ROM Drive (1040)
Hard Disk Drive (1050)
Top Cover (1060)
Keyboard Unit (1070)
LCD Assembly (1080)
LCD Panel (1085)
Indicator Card (1090)
Volume Switch / Speaker (1100)
Keyboard Card (1110)
To remove the system board and CPU Card:
1 2
3
Step Screw Location (Quantity) Length
1 CPU Card to System Board (1) M2 x 4
mm
2 CPU Card to System Board (2) M2 x 5
mm
Note: Make sure you use the correct screws when replacing.
ThinkPad 365X, 365XD (2625) 159
