16
Insignia NS-PDVD8 8.5" Personal DVD Player
www.insignia-products.com
3 Plug the red connector into the AUDIO IN R jack on the TV.
4 Plug the white connector into the AUDIO IN L jack on the TV.
Connecting a TV and amplifier
To connect a TV and amplifier:
1 Plug the mini AV connector into the AV OUT jack on the right side
of your player.
2 Plug the yellow connector into the VIDEO IN jack on the TV.
3 Plug the red connector into the AUDIO IN R jack on the amplifier.
4 Plug the white connector into the AUDIO IN L jack on the
amplifier.
Tip
If your amplifier has a coaxial digital input jack, you can
connect your player to your amplifier using the COAXIAL
OUT jack on your player.
AV OUT AV IN COAXIAL DC OUT 5V DC IN 9V PHONE-3
VIDEO IN
AUDIO IN R
AUDIO IN L
OPNCAL
LINE IN
SPEAKWRS
R L
R L
TV
R-Speaker
L-Speaker
Right side of player
Amplifier
