IMPORTANT
ASSEMBLY INFORMATION

Tools required for assembling the equipment: two adjustable wrenches and allen
wrenches.

NOTE: It is strongly recommended that this equipment is assembled by two or more
people to avoid possible injury.
 Ensure Carriage Bolts are inserted through the SQUARE holes on components that need to
be assembled. Attach washer only to end of the Carriage Bolt.
 Insert Allen Bolts or Hex Bolts through the ROUND hole on components that need to be
assembled.

Always wait until all bolts are assembled onto the equipment before tightening the bolts. Do not
fasten each bolt right after it is installed
Fasten Nuts and Bolts
Securely tighten all Nuts and Bolts after all
components have been assembled in current and
previous steps.
NOTE: Do not over tighten any component with
pivotal function.
Make sure all pivotal components are able to move
freely.
Do not tighten all Nuts and Bolts in this step.
©IMPEX INC. 3
