©IMPEX INC. www.impex-fitness.com 8
MKB-2081 PARTS LIST
PART
NO. DESCRIPTION
SIZE QUANTITY
1 Upright Beam 2
2 Cross Brace 1
3 Main Seat Support 1
4 Diagonal Support 1
5 Front Post 1
6 Backrest Support 1
7 Foam Tube 2
8 Backrest Support 2
9 Leg Developer 1
10 Arm Curl Stand 1
11 Seat Pad 1
12 Backrest Board 1
13 Arm Curl Pad 1
14 Bracket 4 3/8” x 3 3/8” 1
15 Bracket 4 ¾” x 3 ½” 2
16 Weight Bar 1
17 End Cap Ø ¾” 4
18 End Cap 1 ½” x 1 ½” 2
19 Foam Roll 4
20 Sleeve 1 ¾”x 1 ½” 1
21 End Cap Ø 1” 6
22 Spring Clip Ø 1” 3
23 End Cap ¾” x ¾” 2
24 Weight Plate 25lb 2
25 Weight Plate 15lb 2
26 Lock Knob 1
27 Carriage Bolt M10 x 2 ½” 4
28 Hex Bolt M10 x 2 1/8” 2
29 Carriage Bolt M8 x 1 5/8” 1
30 Carriage Bolt M8 x 1 ¾” 1
31 Hex Bolt M10 x 2 3/8” 1
32 Hex Bolt M6 x 1 3/8” 4
33 Hex Bolt M6 x 5/8” 4
34 Hex Bolt M8 x ¾” 2
35 Hex Bolt M8 x 3/8” 1
36 Washer Ø ½” 8
37 Washer Ø 5/8” 5
38 Washer Ø ¾” 7
39 Aircraft Nut M8 2
40 Aircraft Nut M10 7
