OSD MENU

POSITION

Changes the position of the OSD
on the screen.

H-POSITION

Same as Analog

V-POSITION

INPUT

SELECTION

This monitor can accept video
signals through two different
connectors.
Most desktop computers use a D-
SUB connector. Select DVI-D
among OSD controls when you
use DVI connector.

1 - selects D-SUB
(Analog)
2 - selects DVI-Analog

3 - selects DVI-Digital

Same as Analog

INFORMATION

Shows information about the
addressability and the horizontal
and vertical frequencies available.
The current setting for the images
received from the computer or
video board is displayed along the
bottom of both submenus.

USER
MODES

Lists all modes which
you have defined by
making changes using
the OSD controls

Same as Analog

PRESET
MODES

Lists all modes that have
been defined during
manufacture

OSD Icon

Description

Sub-
menu(s)

Controls and

Adjustments(Analog)

Controls and

Adjustments(Digital)
