Infinity CC-1 - Manual (Page 8)

Infinity CC-1 Center-Channel Speaker Owner’s Manual ◆ 7
P
ERFORMANCE
D
ATA
D
RIVE
U
NITS
D
IMENSIONS
S
PECIFICATIONS
Frequency Range: 100 ~ 20,000 Hz
Sensitivity: 90 dB @ 2.83 V and 1 m (anechoic conditions)
Impedance: 8
Ω
Maximum Peak Output: 109 dB (spl on program)
Amplifier Requirements: Recommended for use with amplifiers
10 ~ 80W (@ 8
Ω
)
Low/Mid Frequency: 2 x 4" (100 mm) polypropylene cone,
magnetically-shielded
High Frequency: 1 ⁄
2
" (12 mm) elliptical waveguide
Crossover Frequency: 3,000 Hz
Width: 12 1 ⁄
2
" (318.0 mm)
Height: 5" (128.5 mm)
Depth: 7" (178.0 mm)
Weight: 7 1 ⁄
2
lb (3.4 kg)
CC1 Ins 9/11/98 3:42 PM Page 7
