Infinity CC-1 Center-Channel Speaker Owner’s Manual ◆ 5
T
ESTING
T
HE
S
PEAKER
After placing and wiring the speakers, turn on audio system power.
Follow the instructions (packed with your A/V preamplifier or receiver)
to calibrate the Dolby
® Pro Logic channels. Most components include a
built-in test tone to help you balance the sound levels to all speakers in
your system.
During calibration, verify that the CC-1 center-channel speaker
reproduces the test tone. If not, check the wiring connections and see
the Troubleshooting chart (on page 6) for help.
Figure 4. This wiring diagram shows
polarity connections for a center
channel connection (also see the
owner’s manual that came with your
amplifier, receiver, or television).
Receiver or
Amplifier
(rear view)
+ –
CC-1
(rear view)
(one channel shown)
+ red blk –
