IBM X3500 - Manual (Page 11)

A stable, long-life, dual-socket, dual- and quad-core SMP
server, offering high-performance, massive capacity and
outstanding availability
Please see the Legal Information section for important notices and information.
11
x3500 Images
Front View Rear View
Interior View
ServeRAID-
8k Adapter
Retainer
Drive Bay
Cage
Externally Visible
Light Path
Diagnostics Panel
Power Supply
Locking Handle
Processors
Zone Cooling
Shield
Hot-
Swap
Fans
Hot-Swap Power
Supplies
Hot-
Swap
Fan
Hot-
Swap
Fans
12 DIMM Slots
Adapter
Slots
8 Hot-Swap 3.5”
SAS/SATA HDD
Bays
Locking
Drive
Cover
2 Open
5.25” Drive
Bays
Externally Visible
Light Path
Diagnostics Panel
DVD-ROM
Drive
Hexagonal
Ventilation
Holes
Cover
Lock
Cover
Latch
USB 2.0
Ports
Fast Ethernet
Port for BMC
Serial
Port
USB
Ports
Ethernet
Ports
Video
Port
Parallel
Port
Serial
Port
Keyboard
and Mouse
Ports
Hot-Swap Power
and Fans
Adapter
Slots
Rear
Fan
Locking
Cover
Key
