• IBM 3482 InfoWindow II display
•
IBM pSeries and RS/6000
•
IBM Personal Computer COMx ports
•
IBM-compatible PCs utilizing an RS-232C interface
The Serial Attachment (#4250, #4252) will attach using
RS-422A to:
•
IBM RS/6000 and pSeries
•
IBM AS/400 ASCII workstation controller
The attachment and data-stream support provided by the
Ethernet LAN Attachment (#4260, #4262) is similar to that
provided by the 10BASE-T Ethernet Network Print Server
(#4164).
However, the Ethernet LAN Attachment will
operate on both 10- and 100-megabit Ethernet LANs.
Publications
The following 4247 Model V03 publications are shipped
with each printer:
•
Model V03: Quick Setup Guide (hardcopy — English)
•
IBM 4247 Model V03: Safety Information
•
IBM 4247 Model V03: Warranty Information
•
A CD-ROM that contains softcopy in the languages
listed below of the following publications:
− IBM 4247 Model V03: User
′
s Guide
− IBM 4247 Model V03: Programmer
′
s Reference
− IBM 4247 Model V03: Safety Information
− IBM 4247 Model V03: Warranty Information
− Model V03: Quick Setup Guide
The CD contains the above publications in the following
languages: English, French, Brazilian-Portuguese,
German, Italian, Spanish, Danish, Dutch, Finnish,
Norwegian, Swedish, Arabic, Chinese-Traditional,
Chinese-Simplified,
Czech, Hungarian, Polish, Russian,
Turkish.
This CD can also be ordered using form number
SK2T-9359.
All of the above publications are also available in the IBM
Printing Systems Digital Library that can be accessed
from the following Web site:
http://www.ibm.com/printers
Select “Manuals.”
The Quick Setup Guide is also available as hardcopy. The
table below shows the form numbers for selected
languages.
Quick
Setup
Language Guide
English, French, Brazilian-Portuguese, S544-5859
German, Italian, Spanish
Danish, Dutch, Finnish, S544-5860
Norwegian, Swedish
Arabic, Chinese-Traditional, Czech, S544-5861
Hungarian, Polish, Russian, Turkish
The User
′
s Guide contains the following sections:
•
Getting Started
•
Understanding the Operator Panel
• Printer Configuration Menus
•
Setting Up Different Forms Paths
•
Problem Solving
•
Printer and Form Specifications
The Publication Notification System (PNS) is available by
order number or product number.
Customers currently
subscribing to PNS will automatically receive notifications
by e-mail. Customers who wish to subscribe can visit the
PNS Web site location at:
http://www.ibm.com/shop/publications/pns/
The publications listed on the notification can be ordered
by calling the Pubs Support Group in Raleigh at
800-879-2755, option 1.
The IBM Publications Center Portal:
http://www.ibm.com/shop/publications/order
The Publications Center is a WW central repository for
IBM product publications and marketing material with a
catalog of 70,000 items.
Extensive search facilities are
provided, as well as payment options via credit card.
Furthermore, a large number of publications are available
online in various file formats, which can currently be
downloaded free of charge.
Note that PNS subscribers most often order their
publications via the Publications Center.
Technical Information
Specified Operating Environment
Physical Specifications
•
Dimensions in base configuration:
− Width: 720.0 mm (28.3 inches)
− Depth: 400.0 mm (15.8 inches)
− Height: 350.0 mm (13.8 inches)
− Weight: 33.0 kg (72.6 pounds)
•
Cabinet Printer Stand (#4462):
− Top Surface Width: 726 mm (28.6 inches)
− Top Surface Depth: 411 mm (16.2 inches)
− Top Surface Height: 775 mm (30.5 inches)
− Weight: 44.5 kg (98.1 pounds)
− Footprint with Output Tray Attached: 726 mm (W) x
792 mm (D) or 28.6 inches wide x 31.2 inches deep
Operating Environment
Input Voltage Required: Input voltages required for
4247-V03 Universal Power Supply:
•
100 — 127 V ac single-phase grounded 50/60 Hz
• 200 — 240 V ac single-phase grounded 50/60 Hz
Printer Heat Output
•
22 watts (75 Btu/hr) — Idle (100 V — 240 V)
•
215 watts (734 Btu/hr) — Normal operation
•
450 watts (1,536 Btu/hr) — Maximum (100 V — 240 V)
Operating Environment Requirements
•
Temperature: 10
°
to 40
°
C (50
°
to 104
°
F)
•
Relative Humidity: 10% to 90%
•
Max Wet Bulb: 27
°
C (81
°
F)
