CARE AND MAINTENANCE
1. Lubricate moving parts with WD-40 or light oil periodically.
2. Inspect and tighten all parts before using the equipment.
3. The equipment can be cleaned using a damp cloth and mild non-abrasive detergent.
DO NOT use solvents.
4. Examine the equipment regularly for signs of damages or wear.
5. Replace any defective components immediately and/or keep the equipment out of use until
repair.
6.
Failure to examine regularly may affect the safety level of the equipment.
WEIGHT CAPACITY AND DIMENSION
1. Maximum weight on each Butterfly: 100 lbs.
2. Assembled Dimension: 52.5” x 25” x 21.5”
PM-50 PARTS LIST
PART
NO. DESCRIPTION
SIZE QUANTITY
1
Butterfly Stand
1
2
Butterfly Support
1
3
Left Butterfly
1
4
Right Butterfly
1
5 Butterfly
Handle
2
6
Weight Post
2
7
Head Pad
1
8
Rubber Bumper
1 7/8” x 1 7/8”
4
9
Bushing
Ø 1” x Ø 5/8”
8
10
Handle Grip
Ø 1” x 7”
2
11
Olympic Sleeve
2
12
Lock Clip
2
13
End Cap
2” x 2”
2
14
End Cap
1 ¾” x 1 ¾”
2
15
End Cap
Ø 1”
2
16
Hex Bolt
M 10 x 2 3/8”
2
17
Hex Bolt
M10 x 2 ½”
2
18
Hex Bolt
M10 x 2 ¾”
2
19 Aircraft
Nut
M12
4
20 Aircraft
Nut
M10
4
21 Washer
Ø
1”
4
22 Washer
Ø
¾”
10
Allen Wrench (Tool)
4#
1
