Additional platform enhancements include:
• Designed to support up to 2GB** DDR266 memory—
double the bandwidth of PC133 SDRAM memory
• High speed USB 2.0 technology***—up to six ports,
each with up to 40 times the bandwidth of USB 1.1
• AC’97 audio with SoundMAX* with SPX—delivers
exceptional audio performance and excellent value
• Intel‚ Rapid BIOS Boot—accelerates Power on Self Test
(POST) for faster system access
• Intel ® Active Monitor—monitors system temperatures,
power supply voltages, and fan speeds
• Advanced hardware Management ASIC † —configurable
closed-loop fan control for quieter systems
• Intel ® Integrator Toolkit † —automatically configure BIOS
and verify system bill of material (BOM)
• Instantly Available PC (suspend-to-RAM)—enables
advanced power saving features and fast recovery from
standby mode. Intel’s robust implementation requires no
jumpers to set up.
Feature-rich Products
for Maximum Flexibility
With Desktop Boards D845EPT2 and D845EBG2, system
integrators can design and build custom configurations to
meet their customers’ specific technology requirements
while maintaining the flexibility to alter or upgrade later.
Desktop Boards D845EPT2 and D845EBG2 offer the choice
of a Communications and Networking Riser (CNR) or Intel ®
PRO/100 network connection. Three PCI slots on Desktop
Board D845EPT2 (microATX) and six PCI slots on Desktop
Board D845EBG2 (ATX) allow further expansion of the
boards’ capabilities, and an AGP slot enables customized
graphics solutions. A high performance audio solution
featuring SoundMAX* with SPX delivers exceptional sound
and the flexibility to upgrade to multi-channel playback
using CNR cards. User satisfaction and expanded system
performance are enhanced through Intel ® Rapid BIOS Boot,
six USB 2.0 ports (four on the back panel and two to the
front panel), and Ultra ATA/100 disk support.
Complete Solutions in the Box
From e-Commerce to creating personal music libraries,
business and personal users are driving demand for a variety
of complex applications. To ensure that today’s PCs are
ready for the digital world, Intel desktop boards now come
with a full suite of software including Norton* Internet
Security* for virus protection and Internet security, NTI CD-
Maker* for creating music and video CDs, SoundMAX* with
SPX for robust audio functionality, and RealONE* for amazing
audio and brilliant full screen video with broadband
connections. Additionally, Intel ® Integrator Toolkit offers OEMs
the ability to streamline manufacturing and customize fan
control settings.
In addition to the full software suite, boxed Intel Desktop
Boards D845EPT2 and D845EBG2 are unique in that they
include key system integration components. These include
integrated retention mechanisms for AGP 4X cards and
processor thermal solutions, IDE and floppy cables, back
panel I/O shield, and configuration labels. And every boxed
Intel desktop board is backed by a three-year limited warranty
and comprehensive support that Intel customers rely on †† .
Intel ® Desktop Board D845EPT2
REFERENCE CODE KEY FEATURES
D845EPT2 microATX, 4X/2X AGP, AC’97
audio, 3-PCI slots, 6 USB 2.0 ports,
and CNR
D845EPT2L microATX, 4X/2X AGP, AC’97
audio, 3-PCI slots, 6 USB 2.0 ports,
and LAN
D845EPT2LS1 microATX, 4X/2X AGP, AC’97
audio, 3-PCI slots, 6 USB 2.0 ports,
LAN, and CNR
Intel ® Desktop Board D845EBG2
REFERENCE CODE KEY FEATURES
D845EBG2 ATX, 4X/2X AGP, AC’97 audio,
6-PCI slots, 6 USB 2.0 ports, and
CNR
D845EBG2L ATX, 4X/2X AGP, AC’97 audio,
6-PCI slots, 6 USB 2.0 ports, and
LAN
