Attention:

Previous

DS4500

cabling

documentation

identified

incorrectly

the

connections

of

drive

loops

B

and

C

in

DS4500

configurations

with

four

drive

mini

hubs

installed.

Drive

loop

B

was

incorrectly

shown

as

connecting

to

mini

hub

3

and

drive

loop

C

was

incorrectly

shown

as

connecting

to

mini

hub

2.

Do

not

use

the

incorrect

connections

for

drive

loops

B

and

C

that

are

currently

documented

in

the

original

IBM

TotalStorage

DS4500

Fibre

Channel

Cabling

Instructions

(pn

25R0406)

and

the

IBM

TotalStorage

DS4500

Installation

and

Support

Guide.

For

reference,

this

incorrect

connection

scheme

is

shown

in

Figure

6.

Instead,

use

the

correct

connections

(drive

loop

B

connects

to

mini

hub

2

and

drive

loop

C

connects

to

mini

hub

3)

as

shown

in

Figure

5

on

page

7

and

as

described

in

“Configuring

the

drive

loops”

on

page

10

of

this

document.

Overview:

Cabling

a

DS4500

with

two

drive

mini

hubs

Review

the

following

information

carefully

and

then

continue

to

“Configuring

the

drive

loops”

on

page

10

perform

the

drive-side

cabling

for

your

DS4500

Storage

Subsystem.

The

DS4500

Storage

Server

is

currently

shipped

from

the

factory

with

two

drive

mini

hubs

installed

in

mini

hub

slots

4

and

2

as

a

standard

option.

Previously,

these

two

mini

hubs

were

installed

in

mini

hub

slots

1

and

2.

If

the

DS4500

Storage

Subsystem

is

shipped

with

two

drive

mini

hubs

installed

in

mini

hub

slots

4

and

2,

cable

the

storage

expansion

enclosures

as

shown

by

“Storage

Expansion

Enclosures

-

Group

1”

in

Figure

7

on

page

9

using

the

instructions

in

“Configuring

the

drive

loops”

on

page

10

If

this

is

a

new

DS4500

Storage

Subsystem

configuration

and

the

DS4500

is

shipped

with

two

drive

mini

hubs

installed

in

mini

hub

slots

1

and

2,

IBM

recommends

that

you

remove

the

mini

hub

from

slot

1

(the

right

most-position)

and

swap

it

with

the

blank

mini

hub

inserted

in

drive

mini

hub

slot

4

(the

left-most

position).

Then

cable

the

storage

expansion

enclosures

as

shown

by

“Storage

Expansion

Enclosures

-

Group

1”

in

Figure

7

on

page

9

using

the

instructions

in

“Configuring

the

drive

loops”

on

page

10.

By

Drive
loop C

Out

Drive loop D

DS4500
Storage Server

In

First storage expansion
enclosure

First storage expansion
enclosure

Drive
loop A

Drive
loop B

ds45cabx

Figure

6.

Incorrect

drive

loop

cabling

in

DS4500

configuration

with

four

drive

mini

hubs

installed

8
