PARTS LIST
PART
NO. DESCRIPTION
SPEC. QUANTITY
1 Main Frame 1
2 Front Stabilizer 1
3 Rear Stabilizer 1
4 Vertical Seat Post 1
5 Seat Support 1
6 Handle Post 1
7 Handle 1
8 Level Adjustment Knob 4
9 Allen Bolt M8 x 5/8” 4
10 Tension Adjustment Knob 1
11 Lock Knob 3
12 Seat Pad 1
13 Brake Handle 1
14 Left Pedal 1
15 Right Pedal 1
16 Carriage Bolt M8 x 2 7/8” 4
17 Curved Washer Ø 7/8” 4
18 Acorn Nut M8 4
19 Flat Washer Ø 5/8” x Ø 3/8” 4
20 Lock Washer Ø ½” x Ø 3/8” 4
21 Handle Grip 2
22 Round End Cap Ø 1” 2
23 Rectangle End Cap 7/8” x 2” 4
24 Sleeve 4
25 Bottle Rack 1
26 Philips Screw M4 x ¾” 2
27 Brake Bracket 1
28 Brake Pad 1
29 Flywheel 1
30 Flywheel Axle 1
31 Flywheel Ball Bearing 6001 2
32 Stabilizer End Cap 4
33 Aircraft Nut M8 2
34 Roller Wheel 2
35 Allen Bolt M8 x 1 5/8” 2
36 Shroud 1
37 Chain Belt 1
38 Crank 1
39 Crank Axle 1
40 Crank Ball Bearing 6203 2
