MWM-988 PARTS LIST
PART NO
DESCRIPTION
SIZE
QUANTITY
1
Upper Frame
1
2
Vertical Frame
1
3
Base Frame
1
4
Rear Stabilizer
1
5
Leg Developer Holder
1
6
Seat Support
1
7
Leg Developer
1
8
Front Press Base
1
9
Right Butterfly
1
10
Left Butterfly
1
11
Front Press Handle
2
12
Butterfly Cable Bracket
2
13
Arm Curl Stand
1
14
Swivel Pulley Bracket
2
15
Angled Double Floating Pulley Bracket
1
16
Weight Stack Cover
1
17 Guide
Rod
2
18
Lat Bar
1
19
Selector Rod
1
20
Bracket
1 ¾” x 4 ¾”
4
21
U-shaped Bracket
2” x 7”
1
22
Lock Knob
1
23
Foam Tube
2
24 Backrest
Board
1
25
Seat Pad
1
26
Arm Curl Pad
1
27
Large Foam Roll
Ø 1 7/8” x Ø 8 5/8”
2
28
Foam Roll
Ø 7/8” x Ø 7”
4
29
Weight Stack Cover Bracket
2
30
Double Floating Pulley Bracket
2
31
Rear Stabilizer End Cap
2
32
Weight Selector Pin
1
33 Chain
2
34 C-clip
4
35
Selector Stem
1
36 Weight
Plate
14
37 Bushing
Ø1”
8
38
Front Press Axle
3”
1
39
Butterfly Axle
2 5/8”
2
