Table of Contents
Introduction 3
Positioning the projector
5
Video connections 6
Connecting a video device 7
Displaying a video image 8
Connecting a computer 10
Shutting down the projector 11
Troubleshooting your setup 11
Using the keypad buttons 18
Using the remote control 19
Optimizing video images 20
Customizing the projector 20
Using the menus 21
Picture menu 22
Settings menu 27
Maintenance 29
Cleaning the lens 29
Replacing the projection lamp 30
Appendix 32
Specifications 32
Accessories 32
Red LED behavior and projector errors
33
Projected image size 33
Source compatibility 34
Projector dimensions for ceiling mount installations 35
RS-232 terminal specifications 36
For complete details on connecting and operating the projector, refer to this
User’s Guide. Electronic versions of this User’s Guide in multiple languages
are available on our website at www.infocushome.com/support.
The website also has technical specifications (an interactive image size cal-
culator, laptop activation commands, connector pin outs, a glossary, the
product data sheet), a web store to buy accessories, and a page for online
registration.
Important Operating Considerations
Do not place the projector on a tablecloth or other soft covering that may
block the vents. Vents are placed along the left and right sides of the projec-
tor, as well as across the front of the projector.
Do not use a non-approved
ceiling mount. In the unlikely event of the lamp rupturing, discard any edi-
ble items placed in the surrounding area and thoroughly clean the area
along the sides and in the front of the projector.
2 ft (.6m)
2 ft (.6m)
2 ft (.6m)
Do not place objects in the areas along the side and in the front of the projector
