JP8............JP1
JP16 — JP9
PCI-P16C16
Transistor
External Power protection
(Pico Fuse)
External Power LED
indicator
Figure 1-4. PCI-P16C16 Board Layout
JP8...........JP1
JP16 —— JP9
PCI-P16POR16
LED indicator
Figure 1-5. PCI-P16POR16 Board Layout
PCI-P8R8/P16R16/P16C16/P16POR16 User’s Manual (Ver.2.2, 2005/5/5) …
10
