i-7531 CAN Repeater Quick Start User Guide (ver. 1.3, 2008/03/25) -----
1
Quick Start User Guide
1. Introduction
This user guide describes how to implement the i-7531 module into
users’ applications in a quick and easy way. Therefore, it only provides the
basic concepts. If users want to know more detail information about the i-
7531, please refer to the user manual of i-7531 in the product CD or visit
our website as follow:
The purpose of this document is focused on helping users to quickly
familiarize themselves with the i-7531 module. For example, users can
apply the i-7531 module as follow figure:
Backbone of CAN bus
CAN branch
i-7531
i-7531
Extended
CAN bus
Extended
CAN bus
Electronic isolation
i-7531
Backbone use
Extended use
i-7531
i-7531
Electronic isolation
CAN branch
CAN branch
Original
CAN bus
The i-7531 CAN
Repeater
