©IMPEX INC. 7
CARE AND MAINTENANCE
1. Lubricate moving parts with WD-40 or light oil periodically.
2. Inspect and tighten all parts before using the equipment.
3. The equipment can be cleaned using a damp cloth and mild non-abrasive detergent.
DO NOT use solvents.
4. Examine the equipment regularly for signs of damages or wear.
5. Replace any defective components immediately and/or keep the equipment out of use until
repair.
6.
Failure to examine regularly may affect the safety level of the equipment.
WEIGHT CAPACITY AND DIMENSION
1. Maximum weight capacity: 360 lbs.
2. Assembled Dimension: 24” x 38” x 33”
PARTS LIST
PART
NO. DESCRIPTION
SIZE QUANTITY
1 Left Upright Beam 1
2 Right Upright Beam 1
3 Dumbbell Rack 6
4 Base End Cap 2” x 2 ¾” 4
5 End Cap 2” x 2 ¾” 2
6 Square End Cap 1 ½” x 1 ½” 12
7 Carriage Bolt M10 x 2 1/8” 12
8 Washer Ø ¾” 12
9 Aircraft Nut M10 12
