MWB-26780 PARTS LIST
PART
NO. DESCRIPTION
SIZE
QUANTITY
1
Right Upright Beam
1
2
Left Upright Beam
1
3
Main Seat Support
1
4
Cross Brace
1
5
Front Leg
1
6
Arm Curl Stand
1
7
Leg Developer
1
8
Weight Bar
1
9
Main Seat Stabilizer
1
10
Backrest Support
2
11
Foam Tube
2
12
Upright Bracket
2
13
Lock Knob
M10 x 2 ¾”
1
14 Weight
Plate
25lb
2
15
End Cap
1” x 1”
2
16
End Cap
Ø 1”
4
17
Upright End Cap
Ø 2 3/8”
2
18
Bushing
Ø ¾” x 5/8”
2
19
Spring Clip
3
20
Front Leg End Cap
1
21
Sleeve
Ø 2 3/8” x Ø 2”
1
22
End Cap
Ø 2”
3
23 Weight
Plate
15lb
2
24
Foam Roll
4
25
Arm Curl Pad
1
26 Seat
Pad
1
27
Backrest Board
1
28
Backrest Adjustment Bar
1
29
Carriage Bolt
M10 x 3 1/8”
4
30
Carriage Bolt
M10 x 2 3/8”
2
31
Allen Bolt
M8 x ¾”
6
32
Allen Bolt
M8 x 3”
1
33
Flat End Cap
Ø 1”
6
34
Hex Bolt
M6 x 1 ½”
8
35 Washer
Ø
¾”
6
36 Washer
Ø
5/8”
8
37 Washer
Ø
½”
8
38
Self Tapping Screw
ST5 x 3/8”
2
39 Aircraft
Nut
M10
6
40 Aircraft
Nut
M8
1
