Integra DTR-5.6 - Manual (Page 11)

11
Getting to Know the AV Receiver —Continued
O CD IN
This analog audio input is for connecting a CD
player’s analog audio output.
P TAPE IN/OUT
This analog audio input and output are for connect-
ing a recorder with an analog audio input and out-
put, such as a cassette deck, MD recorder, etc.
Q VIDEO 3 IN
A VCR for playback only, or a cable or satellite
receiver can be connected here. There’s S-Video and
composite video input jacks for connecting the
video signal.
R VIDEO 1 IN/OUT and VIDEO 2 IN/OUT
One or two video components can be connected
here for recording and playback, such as a VCR.
There’s S-Video and composite video input and out-
put jacks for connecting the video signal.
S DVD IN
This input are for connecting a DVD player. There’s
S-Video and composite video input jacks for con-
necting the video signal, and stereo (FRONT) and
multichannel 5.1/7.1 jacks for connecting the ana-
log audio signals.
T ZONE 2 SPEAKERS
These terminal posts are for connecting speakers in
Zone 2.
U PRE OUT FRONT L/R, SURROUND L/R,
CENTER, SUBWOOFER, and SURR BACK
L/R
This 5.1/7.1 analog audio output can be connected
to the analog audio input on another power ampli-
fier, for when you want to use the AV receiver as a
preamplifier. The SUBWOOFER jack is for con-
necting a powered subwoofer.
V FRONT, CENTER, SURROUND, and
SURROUND BACK SPEAKERS
These terminal posts are for connecting the front
L/R, center, surround L/R, and surround back L/R
speakers.
W AC OUTLETS
These switched AC outlets can be used to supply
power to other AV components. The type and num-
ber of outlets depends on the country in which you
purchased your AV receiver.
See pages 17–35 for hookup information.
