PARTS LIST
KEY NO DESCRIPTION Q’ty
1 Right Upright Beam 1
2 Left Upright Beam 1
3 Cross Brace 1
4 Main Seat Support 1
5 Leg Developer Holder 1
6 Leg Developer 1
7 Arm Curl Stand 1
8 Curl Bar Handle Support 1
9 Curl Bar Handle 1
10 Glider 2
11 Safety Stop 2
12 Backrest Incline Support 1
13 Lifting Sleeve 1
14 Guide Rod 2
15 Weight Bar 1
16 Backrest Adjustment Bar 1
17 Backrest Support 2
18 Foam Tube 3
19 Bracket 1
20 Arm Curl Pad 1
21 Backrest Board 1
22 Seat 1
23 Safety Catch Hook 2
24 5 ½” x 3 3/8” Bent Bracket 2
25 5 ½” x 3” Bent Bracket 1
26 L-shaped Lock Pin 1
27 Spring Clip 3
28 Axle 1
29 Lock Knob 1
30
∅
3” Con-shaped End Cap 2
31 Ø 3” End Cap 4
32 Vinyl Foam Roll 6
33 Long Olympic Sleeve 2
34 Short Olympic Sleeve 1
35 1 ½” Sleeve 8
36 Bushing 2
37 Axle Bushing 2
38 Grip 2
39 Foam Roll End Cap 6
40 Ø 1” End Cap 1
41
∅
1” Con-shaped End Cap 1
42 1” Square End Cap 2
43 Ø 2 3/8” End Cap 2
44 Ø 3” Sleeve 1
45 M12 Aircraft Nut 1
46 M10 Aircraft Nut 11
47 M10 x 3 ¾” Carriage Bolt 4
48 M10 x 2 3/8” Carriage Bolt 4
49 M10 x 3 ¾” Allen Bolt 2
50
M10 x 2 ¾” Allen Bolt 1
51 M10 x 2 3/8” Allen Bolt 2
52 M10 x 1” Allen Bolt 6
53 M12 x 7 ½” Allen Bolt 1
54 M8 x 1 5/8” Allen Bolt 4
55 M8 x 5/8” Allen Bolt 6
56 M8 x 3/8” Allen Bolt 4
57 Philips Screw 1
58 Ø 5/8” Washer 10
59 Ø ¾” Washer 22
60 Ø 1” Washer 2
61
Ø 1 ½” Bushing 2
#4 Allen Wrench 1
#5 Allen Wrench 1
#6 Allen Wrench 2
#8 Allen Wrench 1
