Please use Intel approved cooling fan.
0
0
0
0
0
We recommend you to apply the thermal paste to provide better heat
conduction between your CPU and heatsink.
0
0
0
0
0
Make sure the CPU fan power cable is plugged in to the CPU fan connector,
this completes the installation.
0
0
0
0
0
Please refer to CPU heat sink user’s manual for more detail installation
procedure.
8. Hook one end of the cooler bracket to the
CPU socket first.
7. Fan assembly.
9. Picture of device set on the motherboard.
