PARTS LIST
KEY NO. DESCRIPTION QUANTITY
1
Main Frame 1
2 Front Stabilizer 1
3 Rear Stabilizer 1
4 Handlebar Post 1
5 Handle Bar 1
6 Computer 1
7 Seat Post 1
8 Seat 1
9 Left Pedal 1
10 Right Pedal 1
11 Seat Post Lock Knob 1
12 Ø 5/8” Washer 3
13 Spring Washer 3
14 M8 Aircraft Nut 3
15 M10 x 3” Carriage Bolt 2
16 Ø 1” Bent Washer 4
17 M10 Acorn Nut 4
18 M8 x 5/8” Allen Bolt 3
19 Ø 7/8” Bent Washer 3
20 Upper Tension Connector 1
21 Middle Computer Sensor Wire 1
22 Lower Computer Sensor Wire 1
23 Lower Tension Connector 1
24 Upper Computer Sensor Wire 1
25 Crank 1
26 T-shaped Knob 1
27 M8 x ¾” Allen Bolt 1
28 Roller Cap 2
29 Rear Stabilizer End Cap 2
30 Bracket 1
31 M10 x 2 3/8” Carriage Bolt 2
32 Tension Adjustment Knob 1
10
