High Mount Wheel Locks
Pull to Lock
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1028399 Strap, Wheel Lock 1 1 1
1025765 Locknut (1/4-28) 1 4 2
1020363 Spacer (1/4 x 1/2 x 1/2") 1 1 3
1026103 Washer, Nylon (1/4 x 1/2 x 1/32") 1 5 4
1055346 Screw, Hex Head (1/4-28 x 3/4") 1 1 5
1055305 Screw, Socket Button Head (1/4-28 x 3/4") 1 2 6
1028411 Spacer (1/4 x 1/2 x 5/32") 1 1 7
1018733 Link, Stop, Black 1 1 8
1006490 Tip, Plastic, Black 1 1 9
1031780-NLA NLA - Handle, Pull/ Lock, Black - Right 1 1 10
1031781-NLA NLA - Handle, Pull/ Lock, Black - Left 1 1 10
1028416 Link, Wheel Lock, Black 1 1 11
1029420 Shoe, Wheel Lock 1 1 12
1055304 Screw, Socket Button Head (1/4-28 x 5/8") 1 1 13
1059284 Screw, Socket Button Head (1/4-28 x 1-1/4") 1 1 14
1026108 Lockwasher (1/4 x 15/32 x 1/64") 1 2 15
1026907 Washer (1/4 x 1/2 x 1/16") 1 1 16
1026096 Clamp, Wheel Lock, Threaded (1") 1 1 17
1026097 Clamp, Wheel Lock, Non-Threaded (1") 1 1 18
1027268 Screw, Allen Head (1/4-20 x 1") 1 2 19
1038552 Wheel Lock, Clamp On, Pull to Lock - Right 1 1 20 A
1038553 Wheel Lock, Clamp On, Pull to Lock - Left 1 1 20 A
1039344 Kit, Wheel Lock Attaching Hardware (1" tubing) 2 1 21 B
Clamp, Wheel Lock, Threaded (1") 1 2
Clamp, Wheel Lock, Non-Threaded (1") 1 2
Screw, Allen Head (1/4-20 x 1") 1 4
A - Includes items 1 - 16.
B - Includes items 17 - 19. NOTE:
70
