Invacare A4 - Manual (Page 47)

Non-Removable Fold Down Side Guards
Item
Number Part Number Description Note
Quantity Per
Package Assembly
1114099 Screw, Hex Head (1/4-28 x 2") 1 8 1
1039232 Cam, Adjustment 1 2 2
1071496 Pin, Roll (3/16 x 3/4") 1 2 3
1114084 Bracket, Support Back, Black -Right 1 1 4
1114085 Bracket, Support Back, Black -Left 1 1 4
1058636 Washer, Nylon (25/64 x 7/8 x 1/32") 1 2 5
1108477 Washer, Nylon (1/4 x 3/4 x 5/8") 1 4 6
1114087 Guard, Side, Folding, Black 1 2 7
1026162 Spacer (1/4 x 3/8 x 11/32") 1 4 8
1040776 Spacer, Nylon (1/4 x 1 x 1/4") 1 4 9
40157X020 Spacer, Coved (1/4 x 1 x 9/16") 1 4 10
1026907 Washer (1/4 x 1/2 x 1/16") 1 14 11
1116005 Bracket, Latch, Black 1 2 12
1039233 Spacer (1/4 x 7/16 x 5/8") 1 2 13
1114077 Latch, Torsion Spring - Right 1 1 14
1114078 Latch, Torsion Spring - Left 1 1 14
1025728 Washer (1/4 x 1/2 x 1/32") 1 2 15
1025765 Locknut (1/4-28) 1 10 16
1141633 Cord, Nylon (6-1/2 ft.) 1 1 17
1012371 Washer, Nylon (3/8 x 7/8 x 1/16") 1 8 18
1114097 Kit, Fold Down Back Mounting Hardware with Side
Guards 2 1 19 A
1114099 Screw, Hex Head (1/4-28 x 2") 1 4 20
1108477 Washer, Nylon (1/4 x 3/4 x 5/8") 1 8 21
1114087 Guard, Side, Folding, Black 1 2 22
40157X020 Spacer, Coved (1/4 x 1 x 9/16") 1 4 23
1026907 Washer (1/4 x 1/2 x 1/16") 1 4 24
1025765 Locknut (1/4-28) 1 4 25
1114149 Kit, Fixed Back Mounting Hardware with Side
Guards 2 1 26 B
A - Includes items 1-18
B - Includes items 20-25 NOTE:
46
To order call toll free 1-800-333-6900, or www.invacare.com
Form No. 02-015
