27 Chapter 3
Connections to Toshiba LTM10C209A (640 x 480 TFT color LCD)
7 LD3 13 P4
8 LD2 14 P5
9 CP2 35 SHFCLK
10 GND 33 GND
11 CP1 38 LP
12 GND 33 GND
13 S 36 FLM
14 GND 34 GND
15 GND 3 GND
16 GND 4 GND
17 VL 5 VCC
18 VL 6 VCC
19 VH 1 +12 V
20 VH 2 +12 V
Table 3.3: Toshiba LTM10C209A LCD (CN35)
LTM10C209A PCM-3370 (CN35)
Pin Name Pin Name
1 GND 3 GND
2 CLK 35 SHFCLK
3 GND 4 GND
4 R0 27 P18
5 R1 28 P19
6 R2 29 P20
7 GND 8 GND
8 R3 30 P21
9 R4 31 P22
10 R5 32 P23
11 GND 33 GND
12 G0 19 P10
Table 3.2: PCM-3370 connection for PLANAR EL LCD (CN35)
